OUTDOOR ENCLOSURE (1 ANT, 1 ETH) Antennas Not Included
OUTDOOR ENCLOSURE (1 ANT, 1 ETH) Antennas Not Included

OUTDOOR ENCLOSURE (1 ANT, 1 ETH) Antennas Not Included

US$56.95
Tax excluded

Designed to withstand the toughest environments, the WRAP-BOX outdoor enclosure is a small, light, yet very solid wireless outdoor enclosure. The WRAP-BOX is rated NEMA-67 providing complete protection against ingress of dust as well as protection against immersion in water.

Wallmount Bracket
In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

Industrial Die-Cast Aluminum Design

Designed to withstand the toughest environments, the WRAP-BOX outdoor enclosure is a small, light, yet very solid wireless outdoor enclosure. The WRAP-BOX is rated NEMA-67 providing complete protection against ingress of dust as well as protection against immersion in water.

Features

- Die-Cast Aluminum, IP 67 rating
- 1 waterproof N-type Antennas option
- 1 Waterproof, quick disconnect RJ-45 connector
- 3 point silicone-rubber gasket
- Pole-top and wall-mount mounting options
- Fits Alix.3x and nano-ITX boards
- OEM brand can be applied in front (serial & ID in the back).

Note: Outdoor Omni directional Antennas, N-type pigtails and wall mount bracket not included

WRAP-BOX-1A1E

Data sheet

Compatible with
Fits Alix.3x and nano-ITX boards
Inside measurements
180mm x 125mm x 46mm
Wall thickness
3mm
Screws
4 Screws for Motherboard and 4 Screws for Enclosure
Cutouts
1 x Antenna, 1 x Ethernet
Enclosure Seal Operating Temperature
-60C to 230C
Heat Trap
+6.5 Celsius under full sun (~100,000 Lux)
Temperature Raise
using a 5-10Watt heat source (WRAP + radio board): +5.5 Celsiu
Material
Die-Cast Aluminum, IP 67 rating
Masts Support
Die-Cast Aluminum, IP 67 rating
Certificate
RoHS
Return Warranty
No Returns
Manufacturer Warranty
1 Year Limited Warranty
