300 Mbps 2.4 GHz MIMO 400mW Radio Card
300 Mbps 2.4 GHz MIMO 400mW Radio Card

300 Mbps 2.4 GHz MIMO 400mW Radio Card

US$49.50
Tax excluded

WLM200N2-26dBm MiniPCI wireless network adapter provides the leading performance of 802.11g/n .  It supports upto 300Mbps physical data rates and upto about 200Mbps actual user throughput for both the uplink and downlink.

In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

Addition of Compex WLM 11n series MiniPCI wireless network adapter to your device, will greatly improve the network performance and achieve higher efficiency in day-to-day activities like File Transfers, Internet Browsing, and Media Streaming. Compex WLM200N2-26dBm MiniPCI network adapter gives high output power of 400 mW for an extended range of wireless coverage.  It is Configured with excellent receiver sensitivity.   WLM200N2-26dBm is the MiniPCI  the apt choice for long distance links where signal levels are low due to minor obstructions such as trees or buildings. It is configured with Atheros chipset, so it is easy to use with all draft IEEE 802.11n compatible WLANs.  It is ideally suitable to integrate into a wide range of OEM devices and applications.

Main Features

Atheros XSPAN family chipset

2.4GHz IEEE 802.11n draft compliant and backward compatible with 802.11b/g

2.4GHz single-band 2x2 MIMO spatial multiplexing technique

Maximum 26dBm output (per antenna port) - 29dBm aggregate

Supports up to 300Mbps physical data rates

Delivers 10 times the throughput and nearly twice the range of legacy 802.11b/g network

Transmission Power Control (IEEE 802.11h TPC)

Multi-Country Roaming Supported (IEEE802.11d Global Harmonization Standard)

2 x MMCX Antenna Connectors

WLM200N2-26

Data sheet

Chipset
AR9223
Host Interface
PCI Interface v2.3 (Type III-A Mini PCI form factor)
Antenna Connectors
2 x MMCX
Storage Humidity
Max 90% (non-condensing)
Operating Humidity
5% to 95% (non-condensing)
Operating Temprature
-20ºC to 70ºC
Storage Temprature
-40ºC to 90ºC
Width
51mm
Height
9mm
Length
59.6mm
Certificate
FCC, RoHS
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
