54~108Mbps 2.4GHz 1W miniPCI Radio card
54~108Mbps 2.4GHz 1W miniPCI Radio card

54~108Mbps 2.4GHz 1W miniPCI Radio card

US$59.95
Tax excluded

Compex introduces the WLM54G-30dBm-ESD wireless 802.11b/g miniPCI high power of 30dBm (1 Watt) with ESD protection.

In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

WLM54G-30-ESD with electrostatic discharge (ESD) protection up to 15KeV is recommended in places where thunderstorms are frequent. ESD protection can protect the card from surge generated by these thunderstorms that would have otherwise be damaged without ESD protection in a similar exposure High power output makes it an excellent choice for long distance applications. Combined with excellent receiver sensitivity and high speed transmission of up to 108Mbps, Compex WLM54G-30dBm-ESD is the miniPCI choice for long distance links, or those where signal levels are reduced due to minor obstructions such as trees or buildings.

WLM54GP30ESD

Data sheet

Chipset
Atheros 2413
Host Interface
PCI Interface v2.3 (Type III-B Mini PCI form factor)
Output (Per Chain)
30dBm (1 Watt) with ESD protection.
Storage Humidity
Max.90% (non-condensing)
Operating Humidity
5% to 95% (non-condensing)
Operating Temprature
-20ºC to 70ºC
Storage Temprature
-40 ºC to 90 ºC
Power
3.3 VDC
Weight
35 grams
Width
47mm
Height
14mm
Length
64.3mm
Certificate
FCC, RoHS
Return Warranty
No Returns
Manufacturer Warranty
No Returns
