WLE200NX Radio Card

WLE200NX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11/a/b/g/n. It supports up to 300Mbps physical data rates and about 200Mbps of actual user throughput for both the uplink and downlink. With the help of dual-band design, you will enjoy universal connectivity to any 802.11 device through your wireless AP or wireless Router.

It is configured with Atheros chipset, so it is easy to use with all draft IEEE 802.11n compatible WLANs.  It is ideally suitable to integrate a wide range of OEM devices

Atheros XB92 reference design
Atheros XSPAN family chipset,P/N AR9280
IEEE 802.11n compliant and backward compatible with 802.11a/b/g
Supports up to 300Mbps physical data rates
Maximum output power 18dBm@802.11a / 20dBm MIMO aggregate
Multi-Country Roaming Supported (IEEE802.11d Global Harmonization Standard)
2 x U.FL Antenna Connectors
Suitable for Embedded System or OEM Project
Affordable and Ideal for various applications

Wireless radio cards are ESD sensitive, especially the RF switch and the power amplifier. To avoid damage by electrostatic discharge, the following installation procedure is recommended:

1. Touch your hands and the bag containing the radio card to a ground point on the router board (for example one of the mounting holes). This will equalize the potential of radio card and router board.
2. Install the radio card in the miniPCI express socket. Install the pigtail cable in the cutout of the enclosure. This will ground the pigtail to the enclosure.
3. Touch the I-PEX connector of the pigtail to the mounting hole (discharge), then plug onto the radio card. Use external lightning protection for outdoor applications.
