WLE600VX 802.11ac/a/b/g/n miniPCI express radio card
WLE600VX 802.11ac/a/b/g/n miniPCI express radio card

WLE600VX 802.11ac/a/b/g/n miniPCI express radio card

US$38.95
Tax excluded
  • Qualcomm-Atheros QCA9882
  • 2.4GHz max 21dBm output power & 5GHz max 20dBm output power (per chain)
  • IEEE 802.11ac compliant & backward compatible with 802.11a/b/g/n
  • 2X2 MIMO Technology & up to 867Mbps
  • MiniPCI Express 1.1 interface
In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

WLE600VX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11ac/a/b/g/n. It supports up to 867Mbps physical data rates,  With the help of dual-band design, you will enjoy universal connectivity to any 802.11 device through your wireless AP or wireless Router.

It is configured with Atheros chipset, so it is easy to use with all IEEE 802.11 compatible WLANs.  It is ideally suitable to integrate a wide range of OEM devices

Qualcomm-Atheros QCA9882
2.4GHz max 21dBm & 5GHz max 20dBm output power (per chain)
IEEE 802.11ac compliant & backward compatible with 802.11a/b/g/n
2x2 MIMO Technology,up to 867Mbps
MiniPCI Express 1.1 interface
Supports Spatial Multiplexing, Cyclic-Delay Diversity(CDD), Low-Density Parity Check (LDPC) Codes,Maximal Ratio Combining (MRC), Space Time Block Code (STBC)
Supports IEEE 802.11d, e, h, I, k, r, v time stamp, and w standards
Supports Dynamic Frequency Selection (DFS)
Cards are individually calibrated for Quality Assurance

Wireless radio cards are ESD sensitive, especially the RF switch and the power amplifier. To avoid damage by electrostatic discharge, the following installation procedure is recommended:

  1. Touch your hands and the bag containing the radio card to a ground point on the router board (for example one of the mounting holes). This will equalize the potential of radio card and router board.
  2. Install the radio card in the miniPCI express socket. Install the pigtail cable in the cutout of the enclosure. This will ground the pigtail to the enclosure.
  3. Touch the I-PEX connector of the pigtail to the mounting hole (discharge), then plug onto the radio card. Use external lightning protection for outdoor applications.
WLE600VX

Data sheet

Chipset
QCA9882
Compatible with
APU1D, APU1D4, APU2B2, APU2B4
Frequency Range
2.412 ~ 2.472 GHz, 5.180 ~ 5.825 GHz
Wireless Standard
802.11n, 802.11g, 802.11b, 802.11ac, 802.11a
MIMO Channels
2×2
Output (Per Chain)
21dBm
Wireless Speed
870Mbps
Interface
1x MiniPCI-e Pin, 2x U.FL Connector
MiniPCI-e Pin
v1.1
Operating Humidity
5% to 95% (non-condensing)
Operating Temprature
-40ºC to 70ºC
Storage Temprature
-40ºC to 90ºC
Depth
3.2 mm
Weight
35g
Width
50.95 mm
Height
30 mm
Certificate
CE, FCC, RoHS Compliance
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
