Availability: Out of stock
The NCA-1515B is a desktop network appliance powered by Intel® Atom® C3000 (codenamed Denverton) Processor, which delivers powerful performance when running opensense and pfsense.
Based on the Intel® i5 8250U processor based on KabyLake-R architecture 8th Generation, the processor improves CPU performance and efficiency in power consumption. According to Intel, the new quad core models are up to 40% faster than their dual core predecessors. Due to the reduced TDP and the same 14nm+ process, the long term performance and throttling behavior will be interesting and depending on the laptop design. The integrated Intel UHD Graphics 620 (Intel Gen 9.5) is untouched from the 8th Gen Kaby Lake chips. With fast dual-channel memory it can reach the performance of a dedicated GeForce 920M.
Contrary to Skylake, Kaby lake now also supports H.265/HEVC Main 10 with a 10-bit color depth as well as Google's VP9 codec. The dual-core Kaby Lake processors announced in January should also support HDCP 2.2. The chip is manufactured in an improved 14nm process with FinFET transistors (14nm+), the same as the 7th Gen Kaby Lake processors. Intel still specifies the TDP with 15 Watts, which is typical for ULV chips. Depending on the usage scenario, the TDP can vary between 7.5 (cTDP Down) and 25 Watts.
Main Features
- Intel® i5 8250U Quad Core Eight Threads Processor (6MB Cache)
- Compact fanless design
- 1 x HDMI Ports, 1 x Display Port, 1 x Power Adapter included, 1 x Audio & Mic Jack
- 2 x GbE Intel LAN ports, 4 x USB 3.0, 2 x antenna hole
- 1 x Mini-PCIe slot for Wi-Fi/3G/4G/LTE, 1 x mSATA mini slot for storage
- 1 x DDR4-2133/2400 SODIMM, max. capacity up to 16 GB
- 2 x RS232 Console Ports (Console Cable not included)
CS8250
Data sheet
- Processor (CPU)
- Intel i5 8250U
- Core
- Quad core eight threads，1.6G，Max. Turbo 3.4G，6MB Cache
- Graphic Chipset
- Integrated Intel HD Graphics 620
- BIOS
- AMI EFI BIOS
- RAM
- Support 1*DDR4 2133/2400 SODIMM memory slot, Max. Support 16GB
- Storage
- 1 x M.2 2280 slot，1 x 2.5”HDD
- Display Port
- 1 x DP, 1 x HDMI
- Ethernet Ports
- 2 x Intel i211-AT 10/100/1000M LAN
- Front Panel I/O
- 2*COM（2*COM RS232/485 is Optional），4*USB3.0，1 x Power Switch，1 x SIM slot
- Rear I/O
- 1 x DC-IN 12V ，2 x USB2.0，1 x HDMI，1 x DP，2 x Intel 1000M LAN, 1 x Audio (Support MiIC and Speaker Same Time)
- Expansion
- 1 x M.2 2280 slot（Support M.2 PCIE X4 and M.2 SATA SSD）； Support 1 x MINI PCIE slot（WIFI/3G/4G choose one from three），embedded SIM socket
- Operating Temprature
- 0℃ ～ +40℃（HDD），-20℃ ～ +50℃（SSD），Surface air flow
- Weight
- 1.3 KG
- Input Power
- DC 12V
- Dimension
- 186 x 126.5 x 66 mm
- Return Warranty
- Standard 30 Days
