FW1010 Compact Fanless Network Appliance with Intel Bay Trail
FW1010 is a revolutionary ultra compact x86 networking system built with Intel® Bay Trail CPU (Atom™ E3825). The central processor comes with hardware-assisted security mechanisms including AES-NI, allowing only authorized software or data to run on FW1010.
FW1010 is a revolutionary ultra compact x86 networking system built with Intel® Bay Trail CPU (Atom™ E3825). The central processor comes with hardware-assisted security mechanisms including AES-NI, allowing only authorized software or data to run on FW1010. With built-in instruction commands, FW1010 helps manage and secure devices connected to local WiFi network, like a compact entry-level firewall or multi-service gateway.
Despite its compact size, FW1010 delivers rich I/O connectivity and scalability. In terms of scalability, FW1010 comes with one HDMI port for high definition display, one console port for device network management, three LAN ports for network connections, two USB ports (one in USB 2.0 and another in USB 3.0 specifications) for external devices, and one antenna hole for signal reception. The rich I/O connectivity makes FW1010 a widely deployable system in small area network environments.
Intel® Bay Trail E3825 CPU (2 Cores)
Compact fanless design
3 x GbE LAN ports, 1 x USB 2.0, 1 x USB 3.0 port, 1 x antenna hole
1 x Mini-PCIe slot for Wi-Fi/3G/4G/LTE, 1 x mSATA mini slot for storage
1 x DDR3L SODIMM, non-ECC 1067 MHz, max. capacity up to 4 GB
1 x Complete Assembeled System 1 x Enclosure with Port Labels (For custom labels contact Sales) 1 x 2GB RAM 1 x Power Adapter (18v 1.2A) 1 x 32GB mSATA (Blank)
Does not Include:
Null modem cable to connect to the serial console Cat 5 ethernet cables to connect to your network HDMI Cable for display
Intel® Bay Trail E3825 1.46GHz (2 cores)
Silver & Black
Max. RAM Capacity
3 x Intel i211 (10/100/1000)
1 x USB2.0, 1 x USB3.0
1 Power button
Windows (Windows 7, Windows 8, WES 7, WES 8), Linux (Fedora 18/Yocto)
