FW1900 Compact Fanless Network Appliance with Intel® Celeron J1900
FW1900 Compact Fanless Network Appliance with Intel® Celeron J1900
FW1900 Compact Fanless Network Appliance with Intel® Celeron J1900
FW1900 Compact Fanless Network Appliance with Intel® Celeron J1900
FW1900 Compact Fanless Network Appliance with Intel® Celeron J1900

FW1900 Compact Fanless Network Appliance with Intel® Celeron J1900

US$235.95
Tax excluded

FW1900 is a revolutionary ultra compact x86 networking system built with Intel® Celeron J1900 Bay Trail processor.

mSATA Storage:
Internal Memory (RAM)
In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

Based on the Intel® Celeron J1900 processor architecture, the processor improves CPU performance and efficiency in power consumption. Thanks to the specially optimized 22 nanometer low-power process (P1271) with tri-gate transistors, performance and energy efficiency have been significantly improved compared to its predecessor. This allows network appliances to operate at ultra-high speed.

Intel LAN and VGA

FW-1900 is equipped with 4 Intel WG82583 1000 Mbps LAN Ports and Integrated Intel VGA for Firewall applications which are dependent on VGA support for installation.



Main Features

  •   Intel® Celeron J1900 Bay Trail processor (4 Cores)
  •   Compact fanless design
  •   1 x VGA Port, 1 x Power Adapter included
  •   4 x GbE Intel LAN ports, 1 x USB 2.0, 2 x antenna hole
  •   1 x Mini-PCIe slot for Wi-Fi/3G/4G/LTE, 1 x mSATA mini slot for storage
  •   1 x DDR3L SODIMM, non-ECC, max. capacity up to 8 GB
FW1900A

Data sheet

Processor (CPU)
Adopt Intel Bay trail-D quad core J1900 (22nm, 2.0GHz, 2MB second Cache)
Max. RAM Capacity
8 GB
Storage
Select from Options
Expansion
2 x Mini-PCIe
Ethernet Ports
4 x Intel WG82583 (10/100/1000)
Color
Black
OS Support
Windows (Windows 7, Windows 10, WES 7, WES 8), Linux Kernel 2.6 or above
Display Port
VGA
LED
Power Switch
USB Compatibility
2 x USB2.0
Input Power
AC 100~240V@50~60 Hz
Button
1 Power button
Audio
N/A
HDMI connector
No
Ethernet Controller
4 x GbE RJ-45 Ports
Suitable
Firewall, Thin Client, Network Appliance
Serial Port Settings
N/A
Antenna Connectors
2
Operating Temprature
0 ~ 40ºC
Depth
36mm, 44mm (SKU B Only)
Weight
1 KG
Width
134mm
Height
124mm
Certificate
EMC (CE Class B, FCC Class B), Safety (UL)
Power Consumption
48W
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty (Direct from CorpShadow)
