CorpShadow's embedded computers are industrial PCs built on single board computers and designed for wide eployment in application specific environments.
Intel® Atom™ processor C2358 2-Core 6 LAN (FW2700)
Reference: FW2700
- Fanless design
- Optional rack mounting kit support
- Screw-locked power plug
- Intel AES-NI new instructions, improves security without slowing response times
- Support up to 8 GB DDR3 Memory
- Intel i210AT LAN controller
- Support Gen.2 LAN Bypass function
-
Atom C2358 CPU built-in Intel QuickAssist Crypto acceleration
-
Fanless design
-
Optional rack mounting kit support
-
Screw-locked power plug
-
Intel AES-NI new instructions, improves security without slowing response times
-
Support up to 8 GB DDR3 Memory
-
Intel i210AT LAN controller
-
Support Gen.2 LAN Bypass function
The FW2700 is a fanless desktop network security system utilizing the cutting edge capabilities of the Intel Rangeley platform (Based on Intel Atom C2358 2-core CPU, System-On-Chip solution). The Atom C2358 CPU built-in Intel QuickAssist Crypto acceleration, it targets at Entry-level UTM, Firewall, VPN, IPS and WAN optimization applications in SMB environment. The system built-in 6 GbE LAN ports, 1 x Non-ECC DDR3 1333 DIMMs, and 36 W power adapter.
Overview:
-
Barebone System
-
Peace of mind for future expansion.
-
Low power consumption to achevie best ROI.
-
Embedded ultra-low voltage Intel Atom 1.8 GHz CPU with Intel ICH8M system logic.
-
6 Gigabit Ethernet (Flexibility to configure as LAN or WAN) ports with by-pass capability.
-
Console cable included for troubleshooting or development purposes.
Does Include:
-
1x server system
-
1x Power supply
-
Null Modem Cable to connect to the serial console.
This product ships in 4 ~ 6 business days.
Data sheet
- Processor (CPU)
- 2-core Intel® Atom™ processor C2358 (Codenamed "Rangeley")
- Color
- Black
- RAM
- Single Channel DDR3 1333 MHz, 1.5 V (Select size from Options)
- Max. RAM Capacity
- 8GB
- Storage
- (Select from options)
- Storage Controller
- 1 x SATA, 1 x CF Slot
- Ethernet Ports
- 6 x GbE RJ-45 onboard
- Ethernet Controller
- 2 x Intel i210AT, 1 x Marvell 88E1543
- Socket Contact
- Memory Socket 1 x 204-pin DIMM
- Firmware
- AMI BIOS 16MB
- Security Acceleration
- Intel QuickAssist Technology
- Watchdog
- Yes
- Internal RTC
- Yes
- OS Support
- Linux Kernel 2.6 or above
- Expansion
- 1 x Mini-PCIe
- Storage Humidity
- 5% to 95% (non-condensing)
- Operating Humidity
- 5% to 90% (non-condensing)
- Operating Temprature
- 0°C to 40°C
- Storage Temprature
- -20°C to 70°C
- Depth
- 5.67" (145.5 mm)
- Weight
- 1.2 kb (2.64 lbs)
- Width
- 6.90" (177 mm)
- Height
- 1.72" (44 mm)
- Certificate
- CE Class B, FCC Class B, RoHS
- USB Device Port
- 2 x Type A
- Return Warranty
- No Returns
- Manufacturer Warranty
- 1 Year Limited Warranty
