FW1900 Compact Fanless Network Appliance with Intel® Celeron J3160
FW1900 Compact Fanless Network Appliance with Intel® Celeron J3160
FW3160 Compact Fanless Network Appliance
FW1900 Compact Fanless Network Appliance with Intel® Celeron J3160
FW1900 Compact Fanless Network Appliance with Intel® Celeron J3160

FW3160 Compact Fanless Network Appliance

US$235.95
Tax excluded

FW3160 is a revolutionary ultra compact x64 networking system built with Intel® Celeron J3160 processor with Intel® AES New Instructions capable. Support Secure boot and Intel® Virtualization technology.



mSATA Storage:
Internal Memory (RAM)
In Stock, Shipping Now

Based on the Intel® Celeron J3160 processor architecture, the processor improves CPU performance and efficiency in power consumption. Thanks to the specially optimized graphics base frequency 320MHz and Graphics Burst Frequency 700MHz, one machine which can act as firewall, router, desktop, display center solution and many many more. With intel built-in technology whic his Termal Monitoring, Secure Key, execute disable bit and Intel AES new instructions makes this system suitable for remote site deployments.

FW3160 is equipped with 4 Intel i210AT 1000 Mbps LAN Ports and Integrated with 2 HDMI Ports, also work as small form factor desktop.



Main Features

  •   Intel® Celeron J3160 Processor (4 Cores)
  •   Compact fanless design
  •   2 x HDMI Ports, 1 x Power Adapter included, 1 x Audio Jack
  •   4 x GbE Intel LAN ports, 2 x USB 3.0, 2 x antenna hole
  •   1 x Mini-PCIe slot for Wi-Fi/3G/4G/LTE, 1 x mSATA mini slot for storage
  •   1 x DDR3L-1600, non-ECC, max. capacity up to 8 GB
  •   1 x RJ45 Console Port (Console Cable not included)
FW3160

Data sheet

Processor (CPU)
Intel Celeron J3160 (Quad Core, 1.6GHz, Turbo boost 2.24 GHz)
Chipset
Intel Integrated chipset
Max. RAM Capacity
8 GB
Storage
1 x mSATA
Expansion
2 x Mini-PCIe
Ethernet Ports
4 x Intel i210AT (10/100/1000)
Color
Black (Custom Colors Available)
OS Support
Windows (Windows 7, Windows 10, WES 7, WES 8), Linux Kernel 2.6 or above
Display Port
2 x HDMI
LED
Power Switch
USB Compatibility
2 x USB3.0
Input Power
DC 12V
Button
1 Power button
Audio
Yes
HDMI connector
Yes
Security Acceleration
Intel® AES-NI
Ethernet Controller
4 x GbE RJ-45 Ports
Suitable
Firewall, Thin Client, Network Appliance, Desktop, Display Client, CPE
Serial Port Settings
N/A
Antenna Connectors
2
Operating Humidity
5% ~ 95% Non-Condensing
Operating Temprature
0 ~ 40ºC
Weight
0.5 KG
Width
107.5mm
Height
39mm
Length
115mm
Certificate
EMC (CE Class B, FCC Class B), Safety (UL)
Power Consumption
48W
System Memory
1 x DDR3L 1600MHz SODIMM
Serial port
RJ45
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty (Direct from CorpShadow)
