ODROID-GO Advance Black Edition (Rev 1.1)

US$75.50
Tax excluded

"ODROID-GO Advance Black Edition" is a DIY Game kit just like the older version ODROID-GO.

Product available for orders

Item is out of stock, you can subscribe to get alert when the item will be back in stock.



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

ODROID-GO Advance Black Edition (equipped with RK3326, which will deliver outstanding performance compared to the latest round of handhelds that came recently into the market.

A DIY project that can move with you, entertain yourself by making a game kit and share the experience with your friends and family.



KIT Includes:



A USB Type-C Power Cable J D-PAD rubber
B Top enclosure K A, B, X, Y button rubber
C Bottom enclosure L battery sticker
D Plastic L/R/L2/R2 trigger, X, Y, power Buttons M Analog joystick
E Plastic D-pad, A, B Buttons N 320×480 TFT LCD
F ODROID-GO-Advance board O 0.5W speaker
G 3000mAh battery P 1.7×5 screws (7 pcs)
H LCD window Q 1.7×8 screws (4 pcs)
I I ~ VI button rubber R Driver



ODROID-GOA

Data sheet

Processor (CPU)
RockChip RK3326(Quad-Core ARM Cortex-A35 1.3GHz) GPU :Mali-G31 Dvalin
Screen Dimensions
3.5inch 320×480 TFT LCD (ILI9488, MIPI interface)
Storage
SPI Flash(16Mbytes Boot), Micro SD Card slot(UHS-1 Capable interface)
I/O
USB 2.0 Host x 1, 10Pin port(I2C, GPIO, IRQ at 3.3Volt)
Charging Time
2.5~3 hours when the device turns off. When you play game, it takes 4~5 hours.
Button
F1, F2, F3, F4, F5, F6, A, B, X, Y, Direction Pad, Left Shoulder, Right Shoulder, Left Shoulder2, Right Shoulder2, Analog joystick
Audio
Earphone Jack, 0.5Watt 8Ω Mono
Battery Type:
Li-Polymer 3.7V/3000mAh, Up to 9 hours of continuous game playing time
Wireless Standard
Built-in 2.4Ghz 802.11b/g/n (ESP-WROOM-S2)
Power Consumption
Game emulation: 300 ~ 550mA (depends on backlit brightness and type of game emulations and the wireless usage)
System Memory
1GB (DDR3L 786Mhz, 32 Bits bus width)
DC Jack supported input voltage
5V input, USB-C power connector: A USB-C charging cable is included in the package
Dimension
155x72x20 mm (6.1×2.8×0.8 inch), Weight: 180 g (6 oz)
