ODROID-H2 System Board
ODROID-H2 System Board

ODROID-H2 System Board

US$134.95
Tax excluded

Very powerful x86 64bit single board computer with large memory capacity and advanced IO ports

On Backorder, Order to Reserve

Item is out of stock, you can subscribe to get alert when the item will be back in stock.

Ships directly from Canada same day.

Power Adapter not included

ODROID-H2 is powered by Intel® Quad-Core Processor J4105 up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread), 14nm with 4MiB Cache

ODROID-H2 is a new generation of computing device with more powerful, more energy-efficient hardware and a smaller form factor. Offering open source support, the board can run various flavors of Linux, including the latest Ubuntu 18.04.
By implementing the eMMC, USB 3.0 and Gigabit Ethernet interfaces, the ODROID-H2 boasts amazing data transfer speeds, a feature that is increasingly required to support advanced processing power on Intel based devices.
This allows users to truly experience an upgrade in computing, especially with faster booting, web browsing, networking, and 3D games.

  • Intel Quad-core processor J4105 (14nm) with 4MiB Cache, up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread)
  • Dual-channel Memory DDR4-PC19200 (2400MT/s)
  • Total 32GiB RAM Space with two SO-DIMM slots
  • 4 x PCIe 2.0 for one M.2 NVMe storage
  • 2 x Gbit Ethernet ports
  • 2 x SATA 3.0
  • SSE4.2 accelerator (SMM, FPU, NX, MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AES)
  • Intel UHD Graphics 600 (Gen9.5 LP GT1) up to 700Mhz
  • HDMI 2.0 and DP 1.2 multiple 4K/60Hz video outputs



A

CPU (Intel Celeron J4105 Processor)

K

1 x DisplayPort 1.2

B

2 x DDR4 SO-DIMM slots (Dual channel memory support)

L

2 x RJ45 Ethernet Ports (10/100/1000)

C

1 x M.2 PCI Express Module Socket (NGFF-2280)

M

5 x System LED Indicators

D

1 x eMMC (Embedded Multimedia-Card) Socket

N

1 x Peripheral Expansion Header (20-pin)

E

2 x SATA Power Connectors

O

1 x Power Switch

F

2 x SATA3 6.0 Gb/s Data Connectors

P

1 x Reset Switch

G

1 x DC Power Jack

Q

1 x Backup Battery Connector (2-pin)

H

2 x USB 3.0

R

1 x Active Cooling Fan Connector (4-pin)

I

2 x USB 2.0

S

1 x Audio out
1 x Audio in
1 x SPDIF out

J

1 x HDMI 2.0



ODROID-H2

Data sheet

Processor (CPU)
Intel Celeron J4105 Processor (14nm, TDP 10W)
CACHE
4MB L2 Cache
Ethernet Ports
2 x GbE LAN ports (RJ45, supports 10/100/1000 Mbps) (WOL)
Storage Controller
1 x eMMC (Bootable), 2 x SATA3 6Gbps, 1 x M.2 NVMe slot (PCIe 2.0 x 4, supports NGFF-2280 cards)
GPU
UHD Graphics 600 (Gen 9.5 LP GT1 up to 700MHz)
Display Port
1 x DisplayPort 1.2 (up to 4K@60Hz), 1 x HDMI 2.0 (up to 4K@60Hz) (Dual simultaneous display support)
Audio
1 x Audio out (3.5mm jack), 1 x Audio in (3.5mm jack), 1 x SPDIF out (ALC662, HDA codec)
Ethernet Controller
Realtek RTL8111G
Internal RTC
Yes
Power
DC 14V ~ 20V (up to 60W)
Weight
285 g including heatsink
Cooling
Passive (Fan-less design)
CPU frequency
Up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread)
System Memory
2 x DDR4 1.2V SO-DIMM slots, Dual Channel. Max Memory capacity 32GB
Dimension
110mm x 110mm x 47mm
