Connector Pack for ODROID-C0
Connector Pack for ODROID-C0

Connector Pack for ODROID-C0

US$2.43
Tax excluded

This is a perfect connector pack for various DIY projects with the ODROID-C0You need a soldering skill to use this pack.

In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

This is a perfect connector pack for various DIY projects with the ODROID-C0You need a soldering skill to use this pack.

Most of connectors are identical to the ODROID-C1+.
There are two different USB host connectors in this package.
If you want to make a lower profile board, use a single layer connector.
If you want to make a full connectivity, use a dual layer connector

A. Double Layer USB Type-A 8-Pin DIP Jack Connector

B. Single Layer USB Type-A 4-Pin DIP Jack Connector

C. IR(InfraRed) Receiver Sensor
This is a remote control receiver module that can accept standard 37.9Khz carrier frequency based wireless data.

D. UART Console Connector
Molex 5268-04a(2.5mm pitch) is mounted on the PCB.
Its mate is Molex 50-37-5043 Wire-to-Board Crimp Housing.

E. 7-pin Strip Male Header
Add pins to the audio I2S interface holes in the ODROID-C0.
2.54mm(0.1inch) pitch

F. 20x2-pin Strip Male Header
Add pins to the 40pin GPIO port.
2.54mm(0.1inch) pitch

CPOC0
