ODROID-VU5 : 5Inch Multi-Touch Display
Reference: ODVU5
US$71.50
Ideal product for your custom projects with 5-inch multi-touch screen for ODROID gives users ability to create all-in-one. A great choice for projects such as tablets, game console and embedded systems.
The 800 x 480 display connects varity of ODROID boards like ODROID-C2/C1+ via HDMI link board and micro-USB link board which can handles power and signal. This display is compatible with Linux and Android on ODROID C1+, ODROID-C2 and ODROID-XU4.
Ships directly from Canada same day
Specifications
- 5-inch TFT-LCD
- Screen Resolution: 800x480 pixels
- 5 finger capacitive touch input
- Power consumption : 500mA/5Volt
- Backlight on/off slide switch
- Viewing angle (in degree) : Left 70, Right 70, Up 70, Down 50
- Screen Dimensions : 121 x 93.31 x 15 mm Including switch and connectors)
- Viewable screen size : 108 x 64 mm (active area)
PACKAGE INCLUDES :
A. Fully assembled 5inch TFT LCD + 5 point multi touch screen
B. 6 x 3.5mm screws
C. 3 x Hex nuts
D. Micro USB link board
E. HDMI link board
F. Micro-to-TypeA USB Cable (approx. 35cm)
G. Micro-to-Micro USB Cable (approx. 35cm)
H. TypeA-to-TypeA HDMI cable (approx. 35cm)
ODVU5
Data sheet
- Resolution
- 800 x 480 pixels
- LCD
- TFT, SPI Interface
- Aspect Ratio
- 4:3
- Touch Screen
- Resistive
- Touch Screen Controller
- XPT2046 (SPI)
- Colors
- 65536 (16bit RGB-565)
- Weight
- 44 g
- Board Category
- ODROID-C1+
ODROID-C2 - Return Warranty
- No Returns
- Manufacturer Warranty
- No Returns
Ideal product for your custom projects with 5-inch multi-touch screen for ODROID gives users ability to create all-in-one. A great choice for projects such as tablets, game console and embedded systems.
