The ODROID-C1+ is esteemed to be the most powerful low-cost single board computer available, as well as being an extremely versatile device. Featuring a quad-core Amlogic processor, advanced Mali GPU, and Gigabit Ethernet, it can function as a home theater set-top box, a general purpose computer for web browsing, gaming and socializing, a compact tool for college or office work, a prototyping device for hardware tinkering, a controller for home automation, a workstation for software development, and much more.

Some of the modern operating systems that run on the ODROID-C1+ are Ubuntu, Android, Fedora, ARCHLinux, Debian, and OpenELEC, with thousands of free open-source software packages available. The ODROID-C1+ is an ARM device -- the most widely used architecture for mobile devices and embedded 32-bit computing. The ARM processor’s small size, reduced complexity and low power consumption makes it very suitable for miniaturized devices such as wearables and embedded controllers.


* Amlogic ARM® Cortex®-A5(ARMv7) 1.5Ghz quad core CPUs
* Mali™-450 MP2 GPU (OpenGL ES 2.0/1.1 enabled for Linux and Android)
* 1Gbyte DDR3 SDRAM
* Gigabit Ethernet
* 40pin GPIOs + 7pin I2S
* eMMC4.5 HS200 Flash Storage slot / UHS-1 SDR50 MicroSD Card slot
* USB 2.0 Host x 4, USB OTG x 1 (power + data capable)
* Infrared(IR) Receiver
* Ubuntu or Android OS

ODROID-C1+

Data sheet

Processor (CPU)
Amlogic ARM® Cortex®-A5(ARMv7) 1.5Ghz quad core CPUs
Monitoring
Red (Power) hooked up to 5V power, Blue (Alive) u-boot is running
Graphic Chipset
Mali™-450 MP2 GPU (OpenGL ES 2.0/1.1 enabled for Linux and Android)
Board Size
85 x 56 mm
RAM
1Gbyte DDR3 SDRAM
Ethernet Ports
1 Gigabit Ethernet
Package Includes
ODROID-C1+
PMIC
NCP372 Over-voltage, Over-current, Reverse-voltage protection IC from OnSemi.
HDMI connector
Micro-HDMI Port
OS Support
Ubuntu, Android, Fedora, ARCHLinux, Debian, and OpenELEC
Expansion
Infrared(IR) Receiver, 40pin GPIOs + 7pin I2S
Power
5V power input, with an inner diameter of 0.8mm, and an outer diameter of 2.5mm
Board Category
ODROID-C1+
Return Warranty
No Returns
Manufacturer Warranty
1 Year Limited Warranty

Download

ODROID-C1/C1+ Manual

Download (7.11M)
