Ships directly from Canada same day.

Power Adapter not included

ODROID-H2+ is powered by Intel® Quad-Core Processor J4115 (14nm) up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread), 14nm with 4MiB Cache

ODROID-H2 is a new generation of computing device with more powerful, more energy-efficient hardware and a smaller form factor. Offering open source support, the board can run various flavors of Linux, including the latest Ubuntu 18.04.
By implementing the eMMC, USB 3.0 and Gigabit Ethernet interfaces, the ODROID-H2 boasts amazing data transfer speeds, a feature that is increasingly required to support advanced processing power on Intel based devices.
This allows users to truly experience an upgrade in computing, especially with faster booting, web browsing, networking, and 3D games.

  • Intel Quad-core processor J4115 (14nm) with 4MiB Cache, up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread)
  • Dual-channel Memory DDR4-PC19200 (2400MT/s)
  • Total 32GiB RAM Space with two SO-DIMM slots
  • 4 x PCIe 2.0 for one M.2 NVMe storage
  • 2 x 2.5Gbit Ethernet ports
  • 2 x SATA 3.0
  • SSE4.2 accelerator (SMM, FPU, NX, MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AES)
  • Intel UHD Graphics 600 (Gen9.5 LP GT1) up to 700Mhz
  • HDMI 2.0 and DP 1.2 multiple 4K/60Hz video outputs
  • RTC / BIOS backup battery is included



A

CPU (Intel Celeron J4115 Processor)

K

1 x DisplayPort 1.2

B

2 x DDR4 SO-DIMM slots (Dual channel memory support)

L

2 x RJ45 Ethernet Ports (10/100/1000/2500)

C

1 x M.2 PCI Express Module Socket (NGFF-2280)

M

5 x System LED Indicators

D

1 x eMMC (Embedded Multimedia-Card) Socket

N

1 x Peripheral Expansion Header (24-pin)

E

2 x SATA Power Connectors

O

1 x Power Switch

F

2 x SATA3 6.0 Gb/s Data Connectors

P

1 x Reset Switch

G

1 x DC Power Jack

Q

1 x Backup Battery Connector (2-pin)

H

2 x USB 3.0

R

1 x Active Cooling Fan Connector (4-pin)

I

2 x USB 2.0

S

1 x Audio out
1 x Audio in
1 x SPDIF out

J

1 x HDMI 2.0

 Note* Please manually install Realtek RTL8125B driver to activate the Ethernet ports. Or the Ethernet ports don’t work due to a missing device driver in Linux Kernel.

ODROID-H2P

Data sheet

Processor (CPU)
Intel Celeron J4115 Processor (14nm, TDP 10W)
CACHE
4MB L2 Cache
CPU frequency
Up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread)
Graphic Chipset
UHD Graphics 600 (Gen 9.5 LP GT1 up to 700MHz)
Max. RAM Capacity
32GB
Storage
1 x eMMC connector (bootable and selectable on BIOS)
Display Port
1 x DisplayPort 1.2 (up to 4K@60Hz), 1 x HDMI 2.0 (up to 4K@60Hz) (Dual simultaneous display support)
Storage Controller
2 x SATA3 6Gbps, 1 x M.2 NVMe Slot (PCIe 2.0 x 4, supports NGFF-2280 cards)
Ethernet Ports
2 x 2.5GbE LAN ports (RJ45, supports 10/100/1000/2500 Mbps (WOL)
Ethernet Controller
Realtek RTL8125B
GPU
UHD Graphics 600 (Gen 9.5 LP GT1 up to 700MHz)
Audio
1 x Audio out (3.5mm jack), 1 x Audio in (3.5mm jack), 1 x SPDIF out (ALC662, HDA codec)
Internal RTC
Yes
Power
DC 14V ~ 20V (up to 60W)
Weight
285 g including heatsink
Cooling
Passive (Fan-less design)
System Memory
2 x DDR4 1.2V SO-DIMM slots, Dual Channe
Dimension
110mm x 110mm x 47mm
Board Category
ODROID-H2+
