The UPS2 for C1 is designed specifically for the ODROID-C1.
Uninterrupted Power Supply is an electrical apparatus that provides emergency power to a load when the input power source, typically mains power, fails. The on-battery runtime of most uninterruptible power sources is relatively short but sufficient to start a standby power source or properly shut down the ODROID-C1

It is equipped with a rechargeable 3,000mAh Lithium Polymer battery and a charger with a booster IC for 5V output.

When the AC power source fails, the UPS2 keeps supplying the power to the ODROID-C1 with the battery. There is a digital output pin to notice the battery low-level warning to the ODROID-C1 to trigger the shutdown process. And the AC power source available, UPS2 will supply the power to the ODROID-C1 again automatically.

It will significantly reduce the risk of data loss by sudden power-down.

Full guide, schematics, PCB layout file and detail information is in our WiKi :

- 3000mAh battery pack
- DC Plug Cable soldered UPS2 board
- 3pin jumper wire (11mm)
- 4 x 20mm PCB spacers (Plastic)
- 4 x 11mm PCB spacers (Metal)
- 4 x 10mm PCB spacers (Plastic)
- 5V/2A Power Supply


The DCDC converters have an automatic shutdown/trip function which is activated when the load is very high even very short period.
The battery pack also has very sensitive protection circuit.
So the in-rush current can disconnect all the electrical path.
In this case, you must unplug the battery connectors and DC-plug to reset the protection circuit.


Data sheet

Compatible with
Package Includes
3000mAh battery pack, DC Plug Cable soldered UPS2 board, 3pin jumper wire (11mm), 4 x 20mm PCB spacers (Plastic), 4 x 11mm PCB spacers (Metal),4 x 10mm PCB spacers (Plastic), 5V/2A Power Supply
Battery Life
4 hrs approx.
Charging Time
1hr 30min ~2 hrs
Idle Current
250 ~ 300mA @5V
Output Current
2000mA @ DC 5V
Input Power
2000mA @ DC 5V
Return Warranty
No Returns
Manufacturer Warranty
No Returns
