PC Engines AMD ALIX2D13 System Board
Reference: ALIX2D13
US$128.00
ALIX 2D13 is a miniITX form factor system board optimized for thin clients, industrial user, wireless access points, internal and external mesh networks, firewalls and embedded applications. (3 LAN / 1 mini PCI / LX800 / 256 MB / USB / Battery)
ALIX 2D13 is a miniITX form factor system board optimized for thin clients, industrial user, wireless access points, internal and external mesh networks, firewalls and embedded applications. (3 LAN / 1 mini PCI / LX800 / 256 MB / USB / Battery)
ALIX2D13
Data sheet
- Compatible with
- Linux, FreeBSD, NetBSD, OpenBSD, FreeDOS, OpenWRT, Mikrotik RouterOS, IPFire Firewall, Debian for Alix, Ubuntu, Meteohub
- Processor (CPU)
- 500 MHz AMD Geode LX800
- DRAM
- 256 MB DDR DRAM
- Monitoring
- Three front panel LEDs, pushbutton
- I/O
- DB9 serial port, dual USB port
- Board Size
- 6 x 6" (152.4 x 152.4 mm)
- Storage
- CompactFlash socket, 44 pin IDE header
- Display Port
- None
- Ethernet Ports
- 3 Ethernet channels (Via VT6105M 10/100)
- Firmware
- tinyBIOS
- Expansion
- 1 miniPCI slot, LPC bus
- Power
- DC jack or passive POE, min. 7V to max. 20V
- Board Category
- ALIX
- Return Warranty
- Standard 30 Days
- Manufacturer Warranty
- 2 Years Limited Warranty
ALIX 2D13 is a miniITX form factor system board optimized for thin clients, industrial user, wireless access points, internal and external mesh networks, firewalls and embedded applications. (3 LAN / 1 mini PCI / LX800 / 256 MB / USB / Battery)
