PC Engines APU1D System Board
Reference: APU1D
The APU1D Platform is the alternate next generation of low cost Alix series (Alix.2D13 & Alix.6F2) from PC Engines. It is a high performance mini-ITX embedded board with AMD G Series (Dual-Core) CPU 1GHz with 64 bit and 512MB L2 cache featuring 3 Realtek Gigabit Ethernet & DDR3-1066 DRAM
Only available on special order.
The APU1D Platform is the alternate next generation of low cost Alix series (Alix.2D13 & Alix.6F2) from PC Engines. It is a high performance mini-ITX embedded board with AMD G Series (Dual-Core) CPU 1GHz with 64 bit and 512MB L2 cache featuring 3 Realtek Gigabit Ethernet & DDR3-1066 DRAM.
The PC Engines APU System Board is a Single Board Computer (SBC) which can be used for a variety of applications like LAN Router, Firewalls, Load Balancer, VPN-Router, Thin Clients, compact Server, NAS etc.
Compact, power efficient and can be booted over the network, via USB-Device, SD-Card, mSATA-SSD-Module and SATA-Connection.
Directly ship from Canada!
Data sheet
- Board Category
- APU1
- Return Warranty
- Standard 30 Days
- Manufacturer Warranty
- 2 Years Limited Warranty
Download
APU1D* Schematic
Download (644.53k)
The APU1D Platform is the alternate next generation of low cost Alix series (Alix.2D13 & Alix.6F2) from PC Engines. It is a high performance mini-ITX embedded board with AMD G Series (Dual-Core) CPU 1GHz with 64 bit and 512MB L2 cache featuring 3 Realtek Gigabit Ethernet & DDR3-1066 DRAM
