Only available on special order.

The APU1D4 Platform is the alternate next generation of low cost Alix series (Alix.2D13 & Alix.6F2) from PC Engines. It is a high performance mini-ITX embedded board with AMD G Series (Dual-Core) CPU 1GHz with 64 bit and 512MB L2 cache featuring 3 Realtek Gigabit Ethernet & DDR3-1066 DRAM.

The PC Engines APU System Board is a Single Board Computer (SBC) which can be used for a variety of applications like LAN Router, Firewalls, Load Balancer, VPN-Router, Thin Clients, compact Server, NAS etc. Compact, power efficient and can be booted over the network, via USB-Device, SD-Card, mSATA-SSD-Module and SATA-Connection.

Directly Ship from Canada!

Instructions for Cooling assembly

APU1D4

Data sheet

Processor (CPU)
1.0 GHz AMD Embedded G-Series T40E APU (Dual-Core, 64 Bit Support, SSE1,2,3, SSSE3 ISA, SSE4A, MMX, AMD-V)
DRAM
4 GByte DDR3-1066 (not expandable)
CACHE
2 x 512 KByte L2 Cache
Monitoring
Three front panel LEDs, pushbutton
I/O
DB9 serial port
Board Size
6 x 6" (152.4 x 152.4 mm)
Storage
Boot from SD card (connected through USB), external USB or m-SATA SSD. 1 SATA + power connector
Display Port
None
Ethernet Ports
3 x 10/100/1000 MBit/s (Realtek RTL8111E)
Firmware
CoreBoot Open Source System BIOS with support for iPXE and USB boot
Expansion
2 x Mini PCIe Slots, 1 x SIM Socket for GSM/UMTS Module, 1 x SATA 6 GBits/s, 1 x mSATA 6GBit/s
Power
12V DC
Board Category
APU1
Return Warranty
Standard 30 Days
Manufacturer Warranty
2 Years Limited Warranty

Download

APU1D* Schematic

Download (644.53k)
