PCEngines Indoor Blue Enclosure for APU & ALIX2D13 is designed for ALIX2D13, APU1D, APU1D4 boards
Assembly notes
Tools needed: Phillips screw driver, 5 mm or 3/16" nut driver. Remove hex nuts from DB9 connector of ALIX board. Mount ALIX board in enclosure, then fasten all screws and hex nuts. CF card can be secured with Kapton tape to the CF socket, or a strip of elastic rubber (e.g. sealing strip for windows) on the inside of the top cover.
CASE1D2BLUU
Data sheet
Compatible with
APU1, APU2, APU3
Color
Blue
Screws
8
Back Cutouts
1 x DC Power Jack, 1 x DB9 Serial, 3 x Ethernet, 2 x USB and 2x SMA antenna Connector
Front Cutouts
3 LEDs and 1 Reset
Material
Anodized or painted aluminum
Application
Indoor Application
Package Includes
1 x Enclosure top, 1 x Enclosure base, 4 x screws to mount system board, 4 x Screws to close enclosure, 4 x Self-Adhesive Feet, 2 x Rubber Plugs for unused SMA holes
Depth
157mm
Weight
330g
Width
168mm
Height
30mm
Certificate
RoHS
Board Category
ALIX
APU1
APU2
APU3
Return Warranty
Standard 30 Days
Manufacturer Warranty
No Returns
