Indoor 1 x LAN Enclosure for ALIX.3
Reference: BOX2C
US$14.95
Aluminum Enclosure designed for WRAP.2* / ALIX.3* boards. Cutouts for 1 LAN, DC jack, 2 SMA, DB9, 3 LEDs in back.
Aluminum Enclosure designed for WRAP.2* / ALIX.3* boards. Cutouts for 1 LAN, DC jack, 2 SMA, DB9, 3 LEDs in back.
Assembly notes
Tools needed: Phillips screw driver, 5 mm or 3/16" nut driver. Remove hex nuts from DB9 connector of ALIX board. Mount ALIX board in enclosure, then fasten all screws and hex nuts. CF card can be secured with Kapton tape to the CF socket, or a strip of elastic rubber (e.g. sealing strip for windows) on the inside of the top cover.
Note: Please Select front bracket for your system board.
BOX2C
Data sheet
- Compatible with
- ALIX3D2, ALIX3D3
- Color
- Silver
- Screws
- 8
- Front Cutouts
- 1 LAN, DC jack, 2 SMA, DB9, 3 LEDs
- Material
- Aluminum
- Application
- Indoor
- Package Includes
- 4 screws to mount system board, 4 screws to close enclosure, 4 self-adhesive feet, 2 or 3 rubber plugs to close unused SMA holes
- Depth
- 113mm
- Weight
- 590g
- Width
- 163mm
- Height
- 30mm
- Certificate
- RoHS
- Board Category
- ALIX
- Return Warranty
- Standard 30 Days
- Manufacturer Warranty
- No Returns
Aluminum Enclosure designed for WRAP.2* / ALIX.3* boards. Cutouts for 1 LAN, DC jack, 2 SMA, DB9, 3 LEDs in back.
