PC Engines AMD ALIX2D2 System Board
PC Engines AMD ALIX2D2 System Board

ALIX2E18 System Board

US$122.00
Tax excluded

PC Engines ALIX2E18 System Board 2 LAN is a low cost minilTX form factor system board optimized for high performance.  This board is replacement of ALIX2D2 board with improvements.

(Available on special order)

Available on Special Order

Item is out of stock, you can subscribe to get alert when the item will be back in stock.



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

PC Engines ALIX 2E18 System Board 2 LAN is a low cost minilTX form factor system board optimized for high performance. This board is a replacement for the ALIX2D2 system boards. This PC Engines ALIX System Board is a Single Board Computer (SBC) which can be used as thin clients, kiosks, educational projects, software defined networks (SDN) or any other special purpose network device like wireless access point, firewall, router etc. This product is still active but not recommanded for new designs.

ALIX.2E changes from ALIX.2D

  • Many passive components changed to current mainstream sizes for better availability.
  • Power system changed to use contemporary components.
  • Common-mode choke added on DC input for lower EMI.
  • Various touch-ups to reduce EMI.



ALIX2E18

Data sheet

Processor (CPU)
500 MHz AMD Geode LX800
DRAM
256 MB DDR DRAM
Storage
CompactFlash socket, 44 pin IDE header
Expansion
2 miniPCI slots, LPC bus
Ethernet Ports
2 Ethernet channels (Via VT6105M 10/100)
I/O
DB9 serial port, dual USB port (external), dual USB (10 pin header, internal)
Board Size
6 x 6" (152.4 x 152.4 mm) - same as WRAP.1E
Display Port
None
LED
Three front panel LEDs
Button
Front Panel Push Button
Firmware
tinyBIOS
Power
DC jack or passive POE, min. 7V to max. 20V
Board Type
ALIX
Return Warranty
Standard 30 Days
Manufacturer Warranty
2 Years Limited Warranty
