PC Engines APU3B4 System Board
    PC Engines APU3B4 System Board
  • On sale!
  • -20%

The PCEngines APU3B4 Platform is targeted at application that require 2 x 3G or LTE modems. This board provides you to enable failover between two diffrent networks even if one modem is not working or in use.

The PC Engines APU System Board is a Single Board Computer (SBC) which can be used for a variety of applications like LAN Router, Firewalls, Load Balancer, VPN-Router, Thin Clients, compact Server, NAS etc.

Compact, power efficient and can be booted over the network, via USB-Device, SD-Card, mSATA-SSD-Module and SATA-Connection.

Directly ship from Canada!

Instructions for Cooling assembly



APU3B4

Data sheet

Processor (CPU)
AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support, 32K data + 32K instruction cache per core, shared 2MB L2 cache.
DRAM
4 GByte DDR3-1333 (not expandable)
I/O
DB9 serial port, 2 USB 3.0 external + 2 USB 2.0 internal, three front panel LEDs, pushbutton
Board Size
6 x 6" (152.4 x 152.4 mm) - same as apu1d, alix2d13 and wrap1e.
Display Port
None
Storage Controller
mSATA, SD Card
Enclosure Cutouts
3 x Ethernet, 1 x USB, 2 x SMA, 3 x LED, 1 x Reset button
Ethernet Ports
3 Gigabit Ethernet channels (Intel i211AT)
Package Includes
System Board APU3B4 with Heat Spreader and Thermal Pads
Firmware
CoreBoot Open Source System BIOS with support for iPXE and USB boot
Expansion
3 miniPCI express (J14 USB or mSATA, with SIM
J15 USB only, with SIM
J16: full miniPCI express, but no SIM, intended for wifi). GPIO header, optional I2C bus, COM2 (3.3V RXD / TXD)
Power Adapter
DC Output: 12v 2A with US Plug
Power
12V DC
Board Category
APU3
Return Warranty
Standard 30 Days
Manufacturer Warranty
2 Years Limited Warranty

Download

AssemblyGuide

Download (315.88k)

APU3 User Manual

Download (754.89k)

APU3 User's Manual

Download (754.89k)
