The APU4D2 Platform is the alternate next generation of low cost APU series (APU1D) from PC Engines. It is a high performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 4 Intel i211AT & DDR3-1333 DRAM.

The PC Engines APU System Board is a Single Board Computer (SBC) which can be used for a variety of applications like LAN Router, Firewalls, Load Balancer, VPN-Router, Thin Clients, compact Server, NAS etc.

Compact, power efficient and can be booted over the network, via USB-Device, SD-Card, mSATA-SSD-Module and SATA-Connection.

Directly ship from Canada!

Instructions for Cooling assembly

APU4D2

Data sheet

Processor (CPU)
AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support, 32K data + 32K instruction cache per core
DRAM
2 GB DDR3-1333 DRAM
CACHE
Shared 2MB L2 cache
I/O
DB9 serial port, 2 USB 3.0 external + 2 USB 2.0 internal, three front panel LEDs, pushbutton
Board Size
6 x 6" (152.4 x 152.4 mm)
Storage
Boot from SD card (internal sdhci controller), external USB or m-SATA SSD. 1 SATA + power connector. mSATA is shared with miniPCI express
Ethernet Ports
4 Gigabit Ethernet channels (Intel i211AT)
Connector
Power Jack: 2.5 mm, center positive
LED
3
Firmware
Coreboot
Expansion
3 miniPCI express (J13 USB or mSATA, apu4*4: with SIM
J14 USB only, with SIM
J15: full miniPCI express, but no SIM, intended for wifi). GPIO header, optional I2C bus, COM2 (3.3V RXD / TXD)
Power
12V DC, about 6 to 12W depending on CPU load
Cooling
Conductive cooling from the CPU to the enclosure using a 3 mm alu heat spreader (included)
Board Category
APU4
Return Warranty
Standard 30 Days
Manufacturer Warranty
2 Years Limited Warranty

Download

APU4 Schematics

Download (335.38k)

APU4 Manual

Download (409.43k)
