Red Indoor Enclosure ALIX2D2/6F2 - 2 LAN
Red Indoor Enclosure ALIX2D2/6F2 - 2 LAN

Red Indoor Enclosure APU2C0/ALIX2D2 - 2 LAN

US$14.95
Tax excluded

Enclosure designed for ALIX.2* boards and APU2C0. Cutouts for 3 LEDs and 1 switch in front, cutouts for DB9, 2 LAN, 3 or 2 SMA connectors, DC jack in back. Enclosure made of anodized or painted aluminum. Dimensions 168 mm wide x 157 mm deep x 30 mm high. RoHS compliant.



In Stock, Shipping Now

Enclosure designed for ALIX.2* boards or APU2C0. Cutouts for 3 LEDs and 1 switch in front, cutouts for DB9, 2 LAN, 3 or 2 SMA connectors, DC jack in back. Enclosure made of anodized or painted aluminum. Dimensions 168 mm wide x 157 mm deep x 30 mm high. RoHS compliant.

Assembly notes

Tools needed: Phillips screw driver, 5 mm or 3/16" nut driver. Remove hex nuts from DB9 connector of ALIX board. Mount ALIX board in enclosure, then fasten all screws and hex nuts. CF card can be secured with Kapton tape to the CF socket, or a strip of elastic rubber (e.g. sealing strip for windows) on the inside of the top cover.

CASE1D1REDU

Data sheet

Compatible with
ALIX2D2
Color
Red
Screws
8
Back Cutouts
1 x DC Power Jack, 1 x DB9 Serial, 2 x Ethernet, 2 x USB and 3x SMA antenna Connector
Front Cutouts
3 LEDs and 1 Reset
Material
Anodized or painted aluminum
Application
Indoor
Package Includes
1 x Enclosure top, 1 x Enclosure base, 4 x screws to mount system board, 4 x Screws to close enclosure, 4 x Self-Adhesive Feet, 3 x Rubber Plugs for unused SMA holes
Depth
157mm
Weight
330g
Width
168mm
Height
30mm
Certificate
RoHS
Board Type
ALIX
Return Warranty
Standard 30 Days
Manufacturer Warranty
No Returns
