Red Indoor Enclosure for APU (3 LAN, 6 SMA)
Red Indoor Enclosure for APU (3 LAN, 6 SMA)

Red Indoor Enclosure for APU/ALIX (3 LAN, 6 SMA)

US$14.95
Tax excluded

PCEngines Indoor Red Enclosure for APU & ALIX2D13 is designed for Following boards

APU Series

In Stock

PC Engines case1d2redu6 - Indoor Enclosure for APU Series, Red

Enclosure with cutouts for 3x LEDs and 1x switch in front, cutouts for DB9, 4x LAN, 6x SMA connectors (2x each on the back, right and left side), DC jack in back. Enclosure made of anodized or painted aluminum.

Use with:

  • ALIX2/6 series boards, APU1/2/3/4 series boards
  • BRK1D (wall mount bracket)
  • PIGSMA (SMA reverse pigtail)

Includes:

  • 4x screws to mount system board
  • 4x screws to close enclosure
  • 4x self-adhesive feet
  • 6x rubber plugs to close unused SMA holes

Assembly notes

Tools needed: Phillips screw driver, 5 mm or 3/16" nut driver. Remove hex nuts from DB9 connector of APU board by using HEXBIT. Mount APU board in enclosure, then fasten all screws and hex nuts.

CASE1D2REDU6

Data sheet

Compatible with
APU1, APU2, APU3 Boards
Color
Red
Screws
8
Back Cutouts
1 x DC Power Jack, 1 x DB9 Serial, 3 x Ethernet, 2 x USB and 6x SMA antenna Connector
Front Cutouts
3 LEDs and 1 Reset
Material
Anodized or painted aluminum
Application
Indoor Application
Package Includes
1 x Enclosure top, 1 x Enclosure base, 4 x screws to mount system board, 4 x Screws to close enclosure, 4 x Self-Adhesive Feet, 2 x Rubber Plugs for unused SMA holes
Depth
157mm
Weight
330g
Width
168mm
Height
30mm
Certificate
RoHS
Board Type
APU1, APU3, APU2, ALIX
Return Warranty
Standard 30 Days
Manufacturer Warranty
No Returns
