pfSense® software is a FreeBSD-based firewall tailored for use as a firewall and router. It includes almost all the features of expensive commercial firewalls, and more in many cases.

Here are some supported features:

  • Firewall
  • State Table
  • NAT
  • Site to Site VPN
  • Redundancy
  • Outbound and Inbound Load Balancing
  • VPN - IPsec, OpenVPN, PPTP
  • PPPoE Server
  • RRD Graphs Reporting
  • Real Time Information - Using AJAX
  • Dynamic DNS
  • Captive portal
  • DHCP Server and Relay

Does Include:

  • 1x server system (Motherboard + Enclosure)
  • 1x pre-installed pfSense® software with 16GB mSATA
  • 1x 12V 2.0 amp power supply (US Plug Standard)
    *For EU or UK Plug, comment in the order
  • Bottom Sticker with Serial number for inventory and Warranty purpose.
    *Customize Sticker with your Logo option is available. (As low as 1$ per sticker)
  •

Does not Include:

  • Null modem cable to connect to the serial console
  • Cat 5 ethernet cables to connect to your network
PFA2E2RK16M

Data sheet

Processor (CPU)
AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support, 32K data + 32K instruction cache per core, shared 2MB L2 cache.
DRAM
2 GByte DDR3-1333 (not expandable)
Monitoring
Three front panel LEDs, pushbutton
I/O
DB9 serial port, 2 USB 3.0 external + + 2 USB 2.0 internal, three front panel LEDs, pushbutton
Board Size
6" x 6" (152.4 x 152.4 mm)
Storage
16GB mSATA
Ethernet Ports
3 Gigabit Ethernet channels (Intel i210AT)
Package Includes
Installed System with pfSense® CE
Firmware
CoreBoot Open Source System BIOS with support for iPXE and USB boot
pfSense® Software Support
Not Included
OS Support
N/A
Expansion
2 miniPCI express (one with SIM socket), LPC bus, GPIO header, I2C bus, COM2 (3.3V RXD / TXD)
Operating System (OS)
pfSense® Community Edition
Return Warranty
No Returns

Download

APU2 Schematics

Download (752.69k)
