Availability: 54 In Stock
pfSense® software is a FreeBSD-based firewall tailored for use as a firewall and router. It includes almost all the features of expensive commercial firewalls, and more in many cases.
pfSense® CE Software ready system with APU4D2
Reference: PFA4D2BK16M
US$251.85
pfSense® software is a FreeBSD-based firewall tailored for use as a firewall and router. It includes almost all the features of expensive commercial firewalls, and more in many cases.
pfSense® software is a FreeBSD-based firewall tailored for use as a firewall and router. It includes almost all the features of expensive commercial firewalls, and more in many cases.
Here are some supported features:
- Firewall
- State Table
- NAT
- Site to Site VPN
- Redundancy
- Outbound and Inbound Load Balancing
- VPN - IPsec, OpenVPN, PPTP
- PPPoE Server
- RRD Graphs Reporting
- Real Time Information - Using AJAX
- Dynamic DNS
- Captive portal
- DHCP Server and Relay
Does Include:
- 1x server system (Motherboard + Enclosure)
- 1x pre-installed pfSense® CE software with 16GB mSATA
- 1x 12V 2.0 amp power supply (Standard US Plug)
*For EU or UK Plug, comment in the order - Bottom Sticker with Serial number for inventory and Warranty purpose.
*Customize Sticker with your Logo option is available. (As low as 1$ per sticker)
Does not Include:
- Null modem cable to connect to the serial console
- Cat 5 ethernet cables to connect to your network
PFA4D2BK16M
Data sheet
- Processor (CPU)
- AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support
- DRAM
- 2 GByte DDR3-1333 (not expandable)
- CACHE
- Shared 2MB L2 cache
- Monitoring
- Three front panel LEDs, pushbutton
- I/O
- DB9 serial port, 2 USB 3.0 external + + 2 USB 2.0 internal, three front panel LEDs, pushbutton
- Board Size
- 6" x 6" (152.4 x 152.4 mm)
- Storage
- Boot from SD card (internal sdhci controller), external USB or m-SATA SSD. 1 SATA + power connector. mSATA is shared with miniPCI express.
- Ethernet Ports
- 4 x Gigabit Ethernet channels (Intel i211AT)
- Package Includes
- Installed System with pfSense® CE
- Firmware
- CoreBoot Open Source System BIOS with support for iPXE and USB boot
- pfSense® Software Support
- Not Included
- OS Support
- Zeroshell, OPNSense, IPFire, IPCOP and much more
- Expansion
- 3 miniPCI express (J13 USB or mSATA, apu4*4: with SIM
J14 USB only, with SIM
J15: full miniPCI express, but no SIM, intended for wifi). GPIO header, optional I2C bus, COM2 (3.3V RXD / TXD) - Power
- 12V DC, about 6 to 12W depending on CPU Load
- Cooling Fan
- No (Passive Cooling)
- Cooling
- Conductive cooling from the CPU to the enclosure using a 3 mm ALU heat spreader
- Operating System (OS)
- pfSense® Community Edition
- Return Warranty
- No Returns
pfSense® software is a FreeBSD-based firewall tailored for use as a firewall and router. It includes almost all the features of expensive commercial firewalls, and more in many cases.
