WLE600VX Dual Antenna Kit
WLE600VX Dual Antenna Kit

WLE600VX Dual Antenna Kit

US$68.85
Tax excluded

WLE600NX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11/a/b/g/n/ac. It supports up to 300Mbps physical data rates and about 200Mbps of actual user throughput for both the up link and down link.

Type of Antennas (QTY 2)
In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

WLE600NX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11a/b/g/n/ac. It supports up to 300Mbps physical data rates and about 200Mbps of actual user throughput for both the uplink and downlink. With the help of dual-band design, you will enjoy universal connectivity to any 802.11 device through your wireless AP or wireless Router.

It is configured with Atheros chipset, so it is easy to use with all draft IEEE 802.11n compatible WLANs.  It is ideally suitable to integrate a wide range of OEM devices

Kit Includes:

1 x  WLE600NX Dual-band 802.11n/ac MIMO 2x2 mini-PCIe
2 x  Pigtail RPSMA Bulkhead to UFL
2 x  Dualband Antenna 5dBi Rubber Duck RP-SMA (2.4-5GHz)

W600VXKDB

Data sheet

Chipset
AR9280
Package Includes
1 x Radio Card, 2 x Radio pigtail, 2 x Antenna
Frequency Range
2.412 ~ 2.472 GHz, 5.180 ~ 5.825 GHz
Wireless Standard
802.11n, 802.11g, 802.11b, 802.11a
MIMO Channels
2× 2
Wireless Speed
300Mbps
Interface
1x MiniPCI-e Pin, 2x U.FL Connector
MiniPCI-e Pin
v1.1
Temperature Range
Operating: -20ºC to 70ºC, Storage: -40ºC to 90ºC
Operating Humidity
5% to 95% (non-condensing)
Depth
3.2 mm
Power
2.7Watts (Max)
Width
50.95 mm
Height
30 mm
Certificate
CE, FCC, RoHS Compliance
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
