Wistron DCMA-82 SuperAG
Wistron DCMA-82 SuperAG

Wistron DCMA-82 SuperAG

US$46.95
Tax excluded

Winstron DCMA82 miniPCI wireless network adapter offers high output power of 400mW, extending the range of embedded devices much further. Combined with excellent receiver sensitivity, Winstron DCMA82-26dBm is the miniPCI of choice for long distance links, or those where signal levels are reduced due to minor obstructions such as tress or buildings.

In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

Built on Atheros chipset, DCMA82 is designed to IEEE802.11b/g standards, is compatible with IEEE802.11a/b/g WLAN.

It is ideal for integration in a wide range of OEM devices.
DCMA-82 is also available in Super-G mode, which delivers better performance at higher throughput for your network connectivity

Main Features:

Atheros AR5414 Chipset

Compatible with IEEE802.11 a/b/g standards

Internal Low Frequency Oscillator for Low Power Sleep Mode

High Output Power of up to 26dBm (400mW)

Multi-country Roaming Support (IEEE802.11d)

Suitable for Embedded System or OEM project

Industry Leading 802.11a/g Throughput & Range

RoHS Compliant

Compatible with RB-411 board

DCMA82

Data sheet

Compatible with
PFSENSE®
Antenna Connectors
2 x MMCX
Operating Temprature
0ºC to 70ºC
Storage Temprature
0ºC to 90ºC
Width
50.8mm
Height
5.5mm
Length
59.6mm
Certificate
RoHS
Return Warranty
No Returns (DOA only)
Manufacturer Warranty
1 Year Limited Warranty
