Perfect for IoT, edge computing, and industrial automation, the Boingfire BFX2-RMRU offers robust performance in a compact, durable design.
(This is a Custom system based on standard BFX2RM)
The Boingfire BFX2RMRU is a high-performance 1U rackmount system designed for enterprise networking, edge computing, and reliable connectivity. This 5G/LTE-ready gateway combines powerful hardware with uninterrupted power backup, making it ideal for mission-critical applications where high-speed wireless connectivity and uptime are essential.
Key Features:
- 5G/LTE Connectivity – Equipped with the Quectel RM520N-GL module, supporting global 5G and LTE networks for ultra-fast, low-latency internet. Includes four high-gain external antennas for optimal signal strength.
- Built-in UPS (20-Minute Backup) – Ensures continuous operation during power outages, keeping your network online without interruption.
High-Performance Hardware – Powered by the Boingfire BFX2 board.
- 1U Rackmount Design – Compact, rugged chassis for easy deployment in server racks, telecom cabinets, or industrial environments.
Enterprise-Grade Reliability – Ideal for business continuity, failover routing, remote sites, and IoT gateways.
Technical Specifications:
Model: BFX2RMRU (Standard Rackmount System)
CPU: Intel Celeron J6412 1.5M Cache (AES-NI)
Memory: Customizable (16GB Standard)
Storage: Customizable (128GB Standard)
5G/LTE Module: Quectel RM520N-GL (Sub-6GHz, global bands)
Antennas: 4x SMA connectors + included high-gain antennas
Backup: Built-in UPS (20-minute runtime)
Networking Ports: 4 x RJ45 (2.5Gbps)
Form Factor: 1U Rackmount
Use Cases:
5G/LTE Failover Router – Automatically switches to cellular when the primary internet connection fails.
Edge Computing Gateway – Local processing for IoT, smart factories, or remote sites.
Enterprise Network Uplink – High-speed wireless WAN for offices, retail, or branch locations.
Mission-Critical Communications – Emergency services, industrial automation, and healthcare.
Why Choose the BFX2RMRU?
Always Online – Built-in UPS guarantees uptime during power fluctuations.
Future-Proof 5G – Ready for next-gen networks with the Quectel RM520N-GL module.
Scalable & Robust – Rackmount design fits seamlessly into professional IT environments.
Available Now – Contact Us for Custom Configurations!
| Processor (CPU) |
Intel Celeron J6412 1.5M Cache (AES-NI) |
| Core |
4 (Quad Core) |
| CPU Frequency |
2.6GHz |
| RAM |
DDR4 3200MHz SODIMM, 32GB (Max) |
| Storage |
1 x eMMC4.5, 1 x SATA2, 2 x mSATA |
| Display Port |
Micro-HDMI |
| Resolution |
4096 x 2160 @ 60Hz |
| Ethernet Ports |
4 x RJ45 (2.5Gbps) |
| Ethernet Controller |
Intel i226-V |
| Watchdog |
Programable 1~255 Sec, 1~255 Mins. Disable |
| Power Button |
1 x Front |
| Reset Button |
1 x Internal |
| Cooling Fan |
Fan-less (Optional) |
| Serial Port |
1 x RJ45 External, 2 x TTL |
| Power |
12V ±10% only |
| Typical Power |
1.6A @ 12V (18W) |
| Max. Power |
5A @ 12V (60W) |
| GPIO |
24-bit GPIOs |
| 5G/LTE |
RM520N-GL |
| UPS |
32W (20 Mins backup) |
| USB |
5 x USB2 (Internal) 1 x USB 2.0, 1 x USB3.0 (Type A) |
| Mini PCIe Slot |
1 x 5G/LTE, 1 x WiFi7(M.2), 2 x mSATA |
| Operating Humidity |
10 – 90% RH |
| Storage Humidity |
5 – 95% RH |
| Operating Temperature |
0°C to 60°C |
| Storage Temperature |
-40°C to + 85 °C |
| Dimension |
17 x 9 x 1.8 IN (LxWxH) |
| Weight |
3.5 Lbs (Approx.) |
