Quad-Core 64-Bit Mini Computer - RK3566

Name: Quad-Core 64-Bit Mini Computer - RK3566
Brand: Firefly
SKU: ROC-RK3566PC
Price: 88.4 USD
Availability: InStock

Accepting Orders

US$88.40

Equipped with RK3566 processor, the mini computer supports 8G large RAM. M.2 interface enables expansion with large hard drive. various sytems and boot ways are supported - with the dedicated application programs and forums, geek fun is endless.

Memory+Storage :

Ask a Quote

Description

ROC-RK3566-PC - 1

ROC-RK3566-PC - 2

ROC-RK3566-PC - 3

ROC-RK3566-PC - 6

ROC-RK3566-PC - 7

ROC-RK3566-PC - 8

ROC-RK3566-PC - 9

ROC-RK3566-PC - 10

ROC-RK3566-PC - 11

ROC-RK3566-PC - 12

ROC-RK3566-PC - 13

Product Details

SoC: RockChip RK3566
CPU: Quad-core 64-bit Cortex-A55, 22nm lithography process, frequency up to 1.8GHz
VPU: Supports 4K 60fps H.265/H.264/VP9 video decoding Supports 1080P 60fps H.265/H.264 video encoding
RAM: 2GB / 4GB / 8GB LPDDR4 32Bit,supports all-data-link ECC
Storage Capacity: 32GB / 64GB / 128GB eMMC M.2 PCIe 2.0 × 1 (Expand with 2242 NVMe SSD)
Advanced GPU: ARM G52 2EE Supports OpenGL ES 1.1/2.0/3.2. OpenCL 2.0. Vulkan 1.1
Integrated Camera Module: 1 × MIPI-CSI camera interfac
Ethernet Ports: Supports Gigabit Ethernet (RJ45. 1000 Mbps)
Audio Output: 1 × HDMI audio output 1 × Earphone output
USB Ports: USB3.0, USB2.0
Display Output: 1 × HDMI2.0. Supports 4K@60fps output 1 × MIPI DSI. Supports 1920*1080@60fps output (or dual-channel 1 × MIPI DSI 2560*1440@60fps)
OS Support: Supports Android 11.0, Ubuntu 18.04, Buildroot + QT, Station OS
Board Size: 90.0 mm × 60.0 mm
Wireless: Supports 2.4GHz/5GHz dual-band WiFi,802.11 a/b/g/n/ac Supports BT5.0
Interface Type: HDMI2.0, USB3.0, USB2.0, MIPI DSI, MIPI CSI, I2C, SPI, UART, ADC, PWM, GPIO, PCIe, I2S, etc.

Reference ROC-RK3566PC-1G8G

ean13 3481724162323

mpn ROC-RK3566PC-1G8G
