Khadas Edge Max

Limited Stock (EOL)
US$233.95
  • Dual-core Cortex-A72 up to 1.8GHz
  • Quad-core Cortex-A53 up to 1.5GHz
  • ARM Mali-T860MP4 GPU
  • 4K VP9 and 4K 10bits H265/H264 video decoders up to 60fps
  • 4GB DDR4 & 128GB eMMC.

Quantity Unit price You Save
21 US$215.95 US$378.00
51 US$179.95 US$2,754.00
101 US$172.95 US$6,161.00

Description

EOL - Limited Stock.

Edge Max:

  • 4GB LPDDR4
  • 128GB EMMC 5.1
  • AP6398S, 802.11a/b/g/n/ac Wi-Fi, 2X2 MIMO with RSDB

Unlimited connectivity:

  • 2X2 MIMO 802.11ac Wi-Fi
  • 4.x Bluetooth (Basic)
  • 5.x Bluetooth (Pro/Max)
  • 10/100/1000 Gbit Lan (w/ Captain Carrier Board)
  • Dual USB-C ports (3.0 + D.P 1,2, USB P.D)
  • Dual USB 2.0 ports
  • HDMI 2.0a 4K@60Hz with CEC.
    .

Advanced Specs:

  • WOL(Wake on Lan)
  • RSDB 802.11ac Wi-Fi
    .

Maker friendly:

  • 40-pin GPIO header
  • Cooling fan header
  • Programmable MCU with 16mb of SPI-Flash
  • Khadas TST (Terry's Smart Tweezers), enter upgrade mode even when bootloader is damaged.
    .

Multimedia experts:

  • HDMI2.0a and a powerful VPU with 10-bit 4K H.265/H264@60fps playback support.
  • Support for dual independent displays over USB-C, HDMI, eDP or MIPI.
    .

Tiny form factor:

  • Thin and light with a dimensions of credit card.
    .

Power Supply:


Multi O/S Supported:

  • Android
  • Ubuntu
  • Debian
  • LibreELEC
  • Dual OS
  • Buildroot
  • U-Boot
    .

In the Box:

  • Edge Board
  • Wi-Fi Antenna x2

Product Details

CPU
Dual-core Cortex-A72 up to 1.8GHz, Quad-core Cortex-A53 up to 1.5GHz
Storage Capacity
4GB DDR4 & 128GB eMMC.
SPI Flash
Programmable MCU with 16mb of SPI-Flash
Advanced GPU
ARM Mali-T860MP4 GPU
HDMI Interface Connector
HDMI2.0a and a powerful VPU with 10-bit 4K H.265/H264@60fps playback support, Support for dual independent displays over USB-C, HDMI, eDP or MIPI.
Display Output
4K VP9 and 4K 10bits H265/H264 video decoders up to 60fps
GPIO
40-pin GPIO header
MCU
Programmable MCU with 16mb of SPI-Flash
Cooling Fan
Cooling fan header
OS Support
Android,Ubuntu,Debian,LibreELEC,Dual OS,Buildroot,U-Boot
Antenna
Wi-Fi Antenna x2
Board Category
Edge Max
KHADAS Boards
KEG1-M-002

Reviews (0)

No reviews
