7'' 1024x600 Touch Display (eDP) for LattePanda Sigma

7'' 1024x600 Touch Display (eDP) for LattePanda...

7'' 1024x600 Touch Display (eDP) for LattePanda Sigma

Name: 7'' 1024x600 Touch Display (eDP) for LattePanda Sigma
Brand: LattePanda
SKU: FIT0950
Price: 99.9 USD
Availability: InStock

Ships in 5~10 Days

US$99.90

This display features IPS screen technology with FULL visual Angle support, 1024 x 600 high resolution, and vibrant colour saturation for excellent picture quality. Designed for HMI and portable projects, it prevents dust with a fully fit design, reduces light reflection, and offers easy installation with double-sided adhesive tape. An eDP interface ensures optimal compatibility with LattePanda Sigma, allowing direct OS or API control over power, brightness, and contrast settings.

Description

Excellent Visual Effect

This display adopts IPS screen technology, supports a FULL visual angle, 1024 x 600 high resolution, and high colour saturation, achieving excellent picture quality.

Designed For HMI and Portable Projects

We have made many product design optimizations for HMI and portable project requirements. For example, HMI scenarios are often complex and dusty. Still, this display uses a fully fit design to perfectly prevent dust from entering the screen and effectively reduce the reflection of light. To make the screen easy to install, the edge comes with special double-sided adhesive tape, which can be quickly and firmly fixed.

Best Compatibility

Unlike other standard HDMI screens, this display uses an eDP interface and is best compatible with LattePanda Sigma. It allows you to set screen power, brightness, contrast, and other parameters directly in the OS or APIs.

FEATURES

Wide viewing angle for enhanced visibility from different perspectives
Multi-touch functionality for intuitive interaction
High-quality display with vivid and accurate colour reproduction
Compact and lightweight design for easy integration into various projects
Durable construction with a 6H surface hardness for scratch resistance
Quick response time for smooth and responsive touch operations
Compatible with the LattePanda Sigma model for seamless integration
Versatile applications in human-machine interface (HMI) and portable projects

APPLICATIONS

LattePanda Sigma Single Board Computer.

SPECIFICATION

Resolution: 1024 x 600 high resolution
Interface: eDP(DP)+I2C(TP)
Transmittance：85%
Surface Hardness： 6H
Response Time: ≤16ms
LCM Luminance: 250 cd/m2
Tapping Durability: 200,000,000 times
Connector: 30cm FPC Extension Cable
Pixel pitch (W×H) 0.1506 × 0.1432 mm
Active area (W×H) 154.21 × 85.92 mm
Dimensions: 180*110*5 mm / 7.1*4.3*0.2 inches
Operating Temperature -20 ～ +70 ℃
Storage temperature -30 ～ +80 ℃
Weight(Screen Only): 157.7g
.

SHIPPING LIST

7 inches eDP Touch Display x1
30cm eDP cable x1

Product Details

Display Resolution: 1024 x 600 high resolution
Transmittance: 85%
Connector: 30cm FPC Extension Cable
Interface: eDP(DP)+I2C(TP)
Dimension: 180*110*5 mm
Operating Temprature: -20 ～ +70 ℃
Storage Temprature: -30 ～ +80 ℃
Weight: 157.7g

Reference FIT0950

Attachments

FIT0950

Datasheet

Download (2.7MB)

Reviews (0)

No reviews
