USB Disk on Module is high performance, embedded solid state drive (SSD) deigned to replace a conventional IDE hard disk drive. USB DOM can be plugged into a standard embedded USB connector commonly found in desktops, portable PC systems and industrial PC Systems. This product is well suited for embedded flash storage applications offering new and expanded functionality as well as more cost-effective designs, better performance and increased reliability.

The USB DOM uses BCH Error Detection code (EDC) and Error Correction Code (ECC) algorithms which correct up to 72bits errors for each 1024-byte block of data depending on spare area of flash memory. High performance is achieved through hardware-based error detection and correction.

D6506-32

Data sheet

Compatible with
General Purpose
Storage
32GB
Flash Type:
MLC
Seq: Write (Max)
17 MB/s
Seq: Read (Max)
32 MB/s
Form Factor
USB DOM
OS Support
Microsoft Windows, MacOS10.x, Linux
Interface
9 Pin USB
MTBF
2 million hours
Data Retention
10 Years
Operating Temprature
0°c to 70°c
Storage Temprature
-40°C to +85°C
Power
Read (0.695W), Write (0.370W)
Weight
6g
Width
21.40mm
Height
6mm
Length
35mm
Certificate
RoHS
Return Warranty
Standard 30 Days
Manufacturer Warranty
3 Years Limited Warranty
