Software
- Preinstalled software: OPNsense®
- License: Open Source + 1 year free Business Edition
.
Hardware Specifications
- SFP28 Ports [25Gbps]: 0
- SFP+ Ports [10Gbps]: 4
- GbE RJ45 Ports [100/1000/2500Mbps]: 4
- USB 3.0 Ports: 1
- Console Port: 1
- Internal Storage: 1TB M.2. Solid State Flash
- Memory: 64GB DDR4
- CPU Cores: 8 (max frequency 3.1Ghz)
- Virtual Interfaces (802.1q VLANS)1: 4093
.
System Performance
- Firewall Throughput: 21.1Gbps
- Firewall Packets Per Second: 1760Kpps
- Maximum Firewall Port to Port Throughput: 9Gbps
- Firewall Port to Port Packets Per Second: 122000
- Concurrent Sessions: 63000000
- New Connections Per Second: 50000
- Firewall Latency (average): 100us
- Firewall Policies (Recommended Maximum)1: 10000
- IPsec VPN Throughput (AES256GCM16): 2.5Gbps
- IPsec VPN Packet Per Second (AES256GCM16): 220Kpps
- Threat Protection Throughput Packet Per Second: 291Kpps
- Threat Protection Throughput: ~3.5Gpbs
- High Availability with State Synchronisation: Requires Two
.
Dimensions
- Height x Width x Depth (mm): 43.8 (1U) x 482.6 (19″) x 302 (274 excl. mount/handle)
- Height x Width x Length (inches): 1.73 x 19 x 11.9 (10.8 excl. mount/handle)
- Form Factor: 19″ Rackmountable
- Weight (appliance only): 4.70Kg
.
Environment
- Power Requirements: 100-240VAC, 50-60Hz
- Maximum Current (Single PSU): 2.6A
- Power Consumption (Typical – Single PSU): 55W
- Heat Dissipation: 187.6 BTU/hr
- Operating Temperature: 0 to +45°C
- Storage Temperature: -20 to +70°C
- Humidity: 10-90% non-condensing
.
Regulatory Compliance
- FCC part 15 Class A, CE, Rohs
