BFN4KB - pfSense® CE Installed

Name: BFN4KB - pfSense® CE Installed
Brand: Boingfire
SKU: PFBFN4KB
Price: 309.95 USD
Availability: InStock

Ships in 5~7 Days

US$309.95

Running on an Intel Atom E3845 processor and supporting a maximum of 8GB DDR3L memory, the BFN4KB seamlessly accommodates the demands of pfSense, delivering high-speed, secure, and reliable network security and routing functionalities.

System comes with 1 year standard Warranty, extended warranty will extend your warranty to 2 Years.

Memory Size:

Storage Size:

Power Supply

Quantity	Unit price	You Save
5	US$302.20	US$38.74
15	US$299.10	US$162.72
50	US$296.00	US$697.39
100	US$291.35	US$1,859.70

Ask a Quote

Description

The BFN4KB Advanced Multi-purpose System is a perfect match for the pfSense box. This versatile platform enhances the functionality of pfSense, a popular open-source firewall and router software. Designed with advanced features such as an Intel Atom E3845 processor and 8GB DDR3L memory support, the BFN4KB system can handle the demands of pfSense with ease, providing high-speed, reliable network security and routing capabilities.

Its four Ethernet Gigabit ports, along with 5G, 4G-LTE and WiFi cards, further complement pfSense's features, allowing for robust connectivity options. With the BFN4KB and pfSense box working in harmony, you can rest assured of a secure, efficient, and high-performance networking environment. Whether you're managing a home network or an enterprise-level infrastructure, the BFN4BK and pfSense combination offers a powerful, flexible, and cost-effective solution.

Product Details

CPU: Intel Atom E3845 2M Cache (AES-NI)
Base Frequency: 1.9GHz
Processor Cores: 4 (Quad Core)
RAM: DDR3L 1333MHz SODIMM, 8GB (Max)
Max. RAM Support: 8 GB
SATA: 1 x SATAII with 3.0Gbps (With Converter Card)
M.2 Socket: Yes (3042 & 3052)
Display Resolution: 2560 x 1600 @ 60Hz
USB Compatibility: 2 x USB2.0
Ethernet Ports: 4 x Gigabit Ethernet Channels (Intel i210AT)
Ethernet Controller: Intel i210AT
LED: Power
Serial ports: 1 x RJ45 External, 2 x TTL
Display Output: HDMI (1.4a)
GPIO: 23-bit GPIOs
Power Button: 1 x Rear Button
Power: 12V ±10% only
Power Adapter: 12v-5A (Fully Loaded System)
Watchdog: Programable 1~255 Sec, 1~255 Mins. Disable
Reset Button: 1 x Rear Button
MiniPCI-e slots: 4
Cooling Fan: Fanless
Storage Humidity: 5 – 95% RH
Operating Humidity: 10 – 95% RH
Operating Temperature: 0°C to 60°C
Storage Temperature: -40 °C to + 85 °C

Reference PFBFN4KB416US

MPN PFBFN4KB416US

Attachments

BFN4K Datasheet

Download (892.06KB)

BFN4 Hardware Guid

Download (0)
