Passive POE injector Set 5.5mm x 2.1mm (Standard)
Passive POE injector Set 5.5mm x 2.1mm (Standard)

Passive POE injector Set 5.5mm x 2.1mm (Standard)

US$5.25
Tax excluded

SET contains two pieces INJECTOR and SPLITTER. It is suitable for using with products that basically do not support Power Over Ethernet

In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

SET contains two pieces INJECTOR and SPLITTER. It is suitable for using with products that basically do not support Power Over Ethernet. Passive Power Over Ethernet - SET is applicable for wide range of network products such as Access Points, Routers, IP cameras, modems, switches, embedded computers or other network devices.

SET is compatible with most devices available on the market such as D-Link, Linksys, Airlive, Senao, Wline, Micronet, Edimax etc. The devices can be supplied standardly up to 50V. (The power adapter is not included - it is possible to use the power adapter of the powered device as access point, IP camera etc.) This Passive PoE range is normally from 30-40 metres/100-130 ft (the real distance depends on the power supply, type of cable and powered device).

Note:  Passive POE does not comply with the IEEE 802.3af specification.

POE-P21

Data sheet

Mode
Injector and Splitter
Pinout
DC jack center positive, 2.1 mm pin. RJ45 pins 4,5 = positive, RJ45 pins 7,8 = negative
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
