Outdoor Ethernet Surge Protector Generation 2

The 2nd generation Ubiquiti Ethernet Surge Protector safeguards your outdoor non-PoE and PoE-based systems from voltage threats such as surges and electrostatic discharge events, which can render an entire network system inoperable. This protector is suitable for use with surveillance cameras, access points, and other Ethernet-equipped devices. Ubiquiti has designed it with two surge-protected Ethernet ports that support Gigabit connection speeds. Furthermore, an external housing guards the Ethernet ports along with the surge protector from outdoor elements.

Tech specs

• Interface Connections: (2) RJ45 Female Connectors
• ESD/EMP Protection: Absorbing Transient Current with Response to Surge Voltage from 100V/s to 1kV/us
• DC Spark-Over Voltage: 90V @ 100V/s
• Maximum Impulse Spark-Over Voltage: 700V @ 1kV/us
• Discharge Current: 10kA+
• Maximum Insulation Resistance: 1G ohm @ 50V
• Maximum Capacitance: 1.0 pF @ 1 MHz
• Data Line Protection: RJ45 10/100/1000 Ethernet
• IEEE 802.3af PoE Support: Yes

Box Contents

• 1 x Ubiquiti Surge Protector

Benefits

• Damaging electrostatic discharge attacks and surges are diverted to the ETH-SP and safely discharged into the ground, so network devices are protected.
• All Ubiquiti® airMAX® devices are equipped with built-in ESD protection, so the ETH-SP adds another layer of protection to your outdoor, high-speed network.
