Main Features
- Support one-way E1 / T1 / J1 digital trunk lines, and support SS7 (TUP / ISUP), PRI, R2 and other signaling.
- Support telephone standards for industrial-grade and data protocols, including SS7 Signaling, PPP, Cisco, HDLC, and Frame Relay data models.
- Line coding format: HDB3 / AMI / B8ZS
- frame format is: CRC4 / non-CRC / ESF / D4T1 / E1.
- The driver layer is fully compatible with Asterisk boards and fully enjoy security and stability of open source.
- No additional drivers are required, to avoid potential risks. Fully use DAHDI / Zaptel driver coming with Asterisk, without installing any patches.
- Support Linux, BSD, CentOS, openSUSE, Fedora, Debian, Ubuntu, AstLinux, FreeBSD, OpenBSD operating system.
- It is based on DMA data reading and writing technology to support fast data transmission, reducing the occupancy rate of the computer CPU significantly.
- Support codeing with A-Law, μ-Law, G.729, G.723, GSM, Speex, ADPCM format.
- Automatically identify of PCI bus voltage (5V or 3.3V).
- Suitable for installation in a 2U or 4U server chassis with PCI-E interface.
.
Technical Specification
- 1 RJ48 interface on board, compatible with T1, E1 or J1 mode.
- It is based on PCI-E 1X and is compatible with 2X, 4X, 8X and 16X.
- Suitable for installation in 2U or 4U server enclosures with PCI-E interface.
- High stability of the firmware output / input.
- Power consumption: 2.73W.
- Working environment temperature: 0 - 50 ℃.
- Storage environment temperature: -40 - 125 ° C.
- Packing size: 230MMX140MMX40MM.
- Package weight: 0.2KG.
.
Suitable operation system
- Linux OS(all versions and distributions above 1.0 or 1.0).
.
System hardware minimum configuration
- CPU: 800-Mhz Pentium III
- Memory: 128Mb
- Available PCI-E slots
