Multi-function AR9342 Embedded Board with on-board Wireless
Multi-function AR9342 Embedded Board with on-board Wireless
Multi-function AR9342 Embedded Board with on-board Wireless

Wireless Embedded Board 2.4GHz 3×3 with MiniPCI-e Slot

US$126.15
Tax excluded

Powerful QCA9558 WiSoC, 700Mhz CPU
CompexWRT and OpenWRT firmware supported
On-board 3×3 450Mbps 802.11n
Dual Radio Solution (on-board 802.11b/g/n radio and 1 miniPCIe slot that supports all Compex 802.11ac radio)
Integrated 48V 802.3af (Option for 24V PoE available)
2 x Gigabit Ethernet Port



In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

Application:

Dual Band, Dual Concurrent AP

802.11a/n+802.11b/g/n AP

Point to Point and Point to Multi-Point Wireless Bridge

Wireless Base Station

Wireless Customer-Premises Equipment (CPE)

Support for Third Party 3G/LTE Radio Module

WPJ558HV

Data sheet

Chipset
QCA9558
LED
14 PIN Connector, 7x LED Indicator
Frequency Range
2.412 ~ 2.472 GHz
Operation Mode
CompexWRT, OpenWRT
MIMO Channels
3 x 3
Output (Per Chain)
23dBm
Interface
1x JTAG 14 Pin Connector, 1x MiniPCI-e Slot 9.2mm, 1x Serial Port 4 Pin Connector, 2x Gigabit Ethernet Port, 3x U.FL Connector
Antenna Connectors
3 x U.FL
Operating Humidity
5% to 95% (non-condensing)
Operating Temprature
-20ºC to 70ºC
Storage Temprature
-40ºC to 90ºC
Reset Button
Yes
Certificate
RoHS
Power Consumption
8.6 Watts
Extra
Surge Arrestor, Watchdog Timer
CPU frequency
700MHz
Architecture
MIPS 74Kc
Size of RAM
128MB
System Memory
16MB
10/100 Ethernet ports
2
MiniPCI-e slots
v1.1
802.3af support
Yes
Passive PoE
24V
802.3at support
Yes
DC Jack supported input voltage
24 – 56V
Maximum Wireless Speed
450Mbps
Operating System (OS)
CompexWRT or OpenWRT
Serial port
Yes
JTAG Port
Yes
Surge Arrestor
Yes
Dimension
105 x 117 x 17mm (W x H x D)
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
