US$335.00

DR4029/DR4019 based on IPQ4029/IPQ4019 chipset is an enterprise wireless module integrated with 2x2 5G high power Radio module and 2x2 2.4G high power Radio module designed specifically to provide users with mobile access to high-bandwidth video streaming, voice, and data transmission for office and challenging RF environment in factories, warehouses establishment

Ask a Quote

Description

Dipole antenna

  • 2 x 2.4G&5G Antenna
  • 5dBi 2.4GHz/5Ghz
  • SMA Plug interface
  • Plastic rod of black
  • RoHS compliance

.

Enclosure

  • Dimension: 132x 119 x 34 mm
  • Aluminum alloy material
  • Support WallysDR40X9

.

Features

  • Featuring with industrial-grade IPQ4029/ IPQ4019 chipset
  • Integrated with 2x 2 5G high power（27dbm per chain） Radio module and 2x2 2.4G high power （27dbm per chain）Radio module
  • Support 4.940GHz to5.825GHz Frequency Range
  • Support 2.412GHz to 2.482GHz
  • Support 2 x 5G MMCX Connectors and 2x2.4G MMCX
  • 5MHz/ 10MHz/20MHz/40MHz/80MHz Bandwidth
  • Support 11ABGN/AC
  • RoHS compliance ensure a high level protection of human health and the environment fromrisks that can be posed by chemicals

.

Applications

  • Security Surveillance
  • Commercial radio coverage
  • Hotel Wireless application
  • Country coverage
  • Forest fire protection engineering
  • Some special scene application



Product Details

DR-AP40X9-A
