N300 High Power Access Point
  • On sale!
  • -50%
N300 High Power Access Point

N300 High Power Access Point

Limited Stock
US$31.98 US$63.95 -50%

W45AP is a 300Mbps indoor ceiling access point for hotels, resorts, hospitals, office buildings, universities and other multi-building campus environments that need to extend wireless network.

Description

W45AP is a 300Mbps indoor ceiling access point for hotels, resorts, hospitals, office buildings, universities and other multi-building campus environments that need to extend wireless network. Adopt independent power amplifier to enhance wireless signal for client devices, such as wireless laptops, tablets and smartphones. With the aesthetic ceiling design, W45AP can be deployed easily on ceiling or in crawlspaces. Also W45AP can be deployed in areas where outlets are scarce or not available with 802.3at compliant.

Ceiling Design

With the aesthetic ceiling design, W45AP can be deployed easily on ceiling or wall.

High Power Design

Adopt independent power amplifier to provide up to 400mW transmission power. Thus the wireless signal is stronger and the coverage is optimized.

Wireless N300 Speed

W45AP transfer rate up to 300Mbps on the 2.4GHz for faster file transfer and smoother video streaming.

Gigabit Ethernet Port

Up to 10X faster data transfer than traditional Fast Ethernet. Ideal for streaming videos, VoIP, music and multimedia applications.

Power over Ethernet (802.3at)

The port on the back panel is PoE 802.3at compliant, which allows both power and data to be carried over a single Ethernet Cable to W45AP. So the W45AP can be deployed in areas where power outlets are scarce or not available.

Industry Wireless Security

W45AP offers multi-level wireless encryption options to prevent unauthorized access and protect your important data.
1. 64/128 bit WEP, WPA-PSK, WPA2-PSK, WPA&WPA2-PSK, WPA, WPA2
2. Wireless Access Control based on the MAC address of wireless adapter

SSID to VLAN Tagging

W45AP can be configured to broadcast up to 4SSID. Each SSID can be tagged to a specified network VLAN for different user access based on established access rights.

Multiple Operating Mode

W45AP can be configured to work as Wireless Access Point, WDS, Universal Repeater mode and help you expand your network.

Centralized Management

W45AP can be managed by the hardware Access Controller (CW500), the administrator can monitor, manage and control the APs more easily.

Now available in Canada!


Package Contents:

  • Wireless N300 High Power Access Point W45AP
  • 1*Mounting Bracket
  • 1*Quick Installation Guide
  • 1*Ethernet cable
  • 1*Resource CD
  • 1*Power Adapter
  • 4*Screws
  • 4*Plastic Bolt



Product Details

LED
Sys
Power
802.3at PoE/DC 12V=1A (11W)
Button
1 * Reset
Working Mode
AP, WDS, Universal Repeater
Wireless Standard
802.11n/g/b
Output (Per Chain)
26dBm
Wireless Speed
300Mbps
Wireless Security Settings
64/128 WEP, WPA-PSK, WPA2-PSK, WPA&WPA2-PSK, WPA, WPA2
AP Type
Fit/Fat AP
Width
144.2mm
Height
40.12mm
Certificate
FCC/CE/RoHS
Length
144.2mm
Storage Humidity
10%~90% non-condensing
Operating Humidity
10%~90% non-condensing
Operating Temprature
-10 ºC to 45 ºC
Storage Temprature
-30 ºC to 70 ºC
Color
White
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
Weight
104.6g
VPN Pass-Through
PPTP, L2TP
Maximum Concurrent Client
20
Interface
1 x Gigabit Ethernet LAN
DHCP Server
Yes
Antenna Connectors
Built in Antenna, 2 x 2dBi Printed Antennas
W45AP
