It is the first open source hardware launched by the Banana Pi team, and also a classic product with the largest cumulative sales of Banana Pi. There are still a lot of clients that apply to various projects.

Ask a Quote

Description

Key Parameter：

  • Allwinner A20 Dual-core 1.0GHz CPU（option:allwinner A40i）
  • Mali-400 MP2 with Open GL ES 2.0/1.1.
  • 1 GB DDR3 memory.
  • 1x SATA interface.
  • 1x Gigabit LAN
  • 1x USB otg and 2x USB 2.0
  • 1X MIC
  • AV vide out
  • HDMI out
  • IR
  • CSI camera interface
  • DSI display interface
  • 26 PIN gpio

Hardware interface:

Bananna Pi BPI-F3 interface.jpg

Product Details

CPU
A20 ARM Cortex-A7 Dual-Core (option:allwinner A40i)
Memory
1GB DDR3
SATA
SATA 2.0
Advanced GPU
ARM Mali 400 MP2; Complies with OpenGL ES 2.0/1.1
LED
Power Key & 8P8C
Audio Output
3.5mm jack and HDMI
USB Ports
2 (direct from Allwinner A20 chip)
Display Output
HDMI, CVBS, LVDS/RGB
GPIO
GPIO, UART, 12C BUS, SPI BUS, WITH TWO CHIP SELECTS, CAN bus, ADC, PWM, +3.3V, +5V, GND
Power
5 volts DC via Micro USB or GPIO
Networking
10/100/1000 Ethernet 8P8C (1000BASE-T)
Video In
A CSI input connector allows for the connection of a designed
