ODROID-HC4 is new Home-Cloud platform based on the same ARM CPU as the ODROID-C4. We adopted a 12nm fabricated energy efficient 1.8Ghz Cortex-A55 quad core processor with faster 4GB DDR4 RAM.
ODROID-HC4 is new Home-Cloud platform based on the same ARM CPU as the ODROID-C4. We adopted a 12nm fabricated energy efficient 1.8Ghz Cortex-A55 quad core processor with faster 4GB DDR4 RAM. A 16MiB SPI flash chip exists on the board for the useful Petitboot feature.
L1 instruction cache: 32 KB, 4-way set associative (128 sets), 64 byte lines, shared by 1 processor, L1 data cache: 32 KB, 4-way set associative (128 sets), 64 byte lines, shared by 1 processor, L3 data cache: 512KB , 16-way set associative (512 sets), 64
I/O
2 x SATA Connectors
Board Size
84mm x 90.5mm x 25.0mm
Color
Clear
Storage
1x Micro SD slot (DS/HS mode up to UHS-I SDR104 (not included)
Display Port
1 x HDMI 2.0 (up to 4K@60Hz with HDR, CEC, EDID)
Ethernet Ports
1 x GbE LAN ports (RJ45, supports 10/100/1000 Mbps)
Ethernet Controller
Realtek RTL8211F (Ethernet transceiver)
GPU
Mali-G31 MP2 GPU with 4 x Execution Engines (650Mhz)
LED
Green LED: Flashing by data traffics at 100Mbps connection, Amber LED: Flashing by data traffics at 1000Mbps connection
Audio
1 x HDMI digital output
IR Receiver
IR receiver for remote controller
Power Adapter
DC 15V/4A power adaptor is recommended
Power
15V/4A
Weight
280g Including Heatsink, fan and case
Architecture
ARMv8-A architecture with Neon and Crypto extensions
System Memory
DDR4 4GiB with 32-bit bus width
Serial port
1 x Debug serial console (UART)
USB Device Port
1 x USB 2.0 host port
Board Category
ODROID-HC
Return Warranty
No Returns
