Reference: ODWB2
Best low-cost environmental sensing solution with BME280 and Si1132 on one board.
The combination of the BME280 sensor and the Si1132 sensor enables measuring temperature, barometric pressure and humidity, UV Index and ambient light at once.
6pin header socket is already soldered. You can simply plug it on to the right connector.
- Dimension is only 16.7 x 16.4 mm
- Sensors : BME280, Si1132
- Recommended working voltage : 1.75 ~ 3.6 Volt
- WiKi Pages (software and hardware guide)
Works with ODROID-SHOW2
http://odroid.com/dokuwiki/doku.php?id=en:wb_odroid_show
Works with ODROID-C Series
http://odroid.com/dokuwiki/doku.php?id=en:wb_c_16x2lcd
Works with ODROID-XU4/3
http://odroid.com/dokuwiki/doku.php?id=en:wb_xu4_shifter_shield
| Pin | Name | Description |
|---|---|---|
| 1 | VDD | Input Voltage 1.75V to 3.55V |
| 2 | SCL | I2c Clock |
| 3 | SDA | I2c Data |
| 4 | ADC3 | Do not connect |
| 5 | INT0 | Interrupt output |
| 6 | GND | Ground |
Data sheet
