802.3at PoE Injector for U6-LR/PRO

The 802.3at PoE+ Injector (U PoE AT) is designed to power 802.3at PoE+ devices. The U PoE AT delivers up to 30W of PoE+ that can be used to power the Access Point WiFi 6 Long-range (U6 LR), Pro (U6 Pro), and other devices that adhere to the 802.3at PoE+ standard. It also provides enhanced protection against electrical surges.

Benefits

• Compatible with the U6LR, U6 PRO and other devices with 802.3at PoE+ standard
• Protection against surge, clamping, maximum surge discharge, peak pulse current, and ESD attacks
• The PoE has built-in earth grounding to protect against ESD damage
• Featuring remote reset for convenient offsite control

Tech specs

• Connector Type: RJ45 Shielded Socket
• Output Voltage: 48VDC @0.65A
• Rated Voltage: 100 - 240VAC @50/60Hz
• Input Current: 0.75A @90VAC
• Line / Load Regulation: <3%, <5%
• 2-Pair Powering: Pins 4, 5 (+) and Pins 7, 8 (-)
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -30°C to 70°C (-22°F to 158°F)
• Operating Humidity: 5 to 90% Noncondensing
• Clamping Protection: 11V Data, 60V Power
• Max. Surge Discharge: 1500A (8/20 micro-s) Power
• Certifications: CE, FCC, IC, UL

Box Contents

• 1 x Ubiquiti PoE Injector (U-POE-AT)
• 1 x Power Cable
