Features
- Featuring withindustrial-grade IPQ4019 chipset
- Integrated with 2x 2 5G high power
- Radio module and 2x2 2.4G high power Radio module
- Support 5.180GHz to5.825GHz Frequency Range;
- Support 2.412GHz to 2.482GHz
- Support 2 x 5G MMCX Connectors and 2x2.4G MMCX
- 20MHz/40MHz/80MHz Bandwidth
- Support 11ABGN/802.11AC
- RoHS compliance ensure a high level.
Applications
- Security Surveillance
- Commercial radio coverage
- Hotel Wireless application
- Country coverage
- Forest fire protection engineering
- Special purpose Application
Specifications
- CPU: IPQ4019（Quad core ARM Cortex A7 at 716.8 MHz）
- Antenna Connector: 2 x 5G MMCX connectors;2x2.4G MMCX
- 10/100/1000Mbps Gigabit Ethernet: 2xRJ45
- DC Jack: 12 power supply
- ROHS Compliance: YES
- Dimension: 65mmx35mm x 16mm
- Max Power: 12V x 0.8A= 9.6W
- Nor Flash: 32MB
- DDR: 256MB
