ODROID-H2 Case Type 1

This “Case Type 1” is designed for the user who needs high bandwidth network with the high capacity storages for the high performance computing system. One 92mm standard PC cooling fan is applied to the side of the enclosure in order to blow out the heated air from the disk drives and the ODROID-H2+.

Supported storages:

On-board eMMC 5.1 module

On-board M.2 NVMe (NGFF-2280)

• Any SATA storage device can’t be installed in the Type 2 cases.

• The disk drive mounting screws (M3x6mm) are included in the package.

• The power and reset switches are accessible through the hole at the front

• Optional power on/off switch (diameter 16mm) can be installed at the front panel
• 128 (L) x 132 (W) x 63 (H) mm



Package contents:

• A. Cooling fan panel

• B. Side panel

• C. Side lock piece

• D. Top panel

• E. Rear panel

• F. Front panel

• G. 1 x 92x92x25mm DC 5V Cooling Fan

• H. 1 x 92mm Stainless Cooling Fan Grill

• I. 4 x 40mm (F) PCB Supports

• J. 4 x 10mm (M) PCB Supports

• K. 4 x M5 PC Fan Screws

• L. 8 x 10mm #6-32 Round Head Screws

• M. 4 x 6mm M3 Truss Head Bolts

Optional accessory

• I2C 20×4 LCD Module

• LED Power Button

• 16Port I2C GPIO Board
